Touch screen temperature controllers for hot runner system injection molding
AST’s KT-600D series temperature controllers provide the most accurate temperature control in the industry. They also feature easy-to-use touch screens and are available in a variety of configurations that can be implemented in any injection molding environment. Operation of all KT-600D series temperature controller is simple and with alarm protection function and all KT-600D series temperature controller can provide very accurate sampling rate of 25 times per millisecond to ensure the accuracy of temperature readings and come with a full one-year warranty.
Specifications
| Mode | Automatic ,manual mode,Selectable soft start modes |
| Cabinet size | 2,8,12and 16 zones etc; Accepted to custom |
| Thermocouple | Type J or K selectable |
| Degree F or C | Selectable |
| Control Accuracy | ±1°c |
| Temperature Range | 50 ~ 550 °c |
Default Set
| Num | Menu | Default Value |
| 1 | Temperature Type | J |
| 2 | Temparature Unit | C |
| 3 | Standby Temperature | 100℃ |
| 4 | Output Mode | PIDD |
| 5 | H-Alarm | 30℃ |
| 6 | L-Alarm | -30℃ |
| 7 | Soft Start | ON |
| 8 | Soft Time | 4Min |
| 9 | Operating Temperature | 120℃ |
| 10 | Language | English |
9 years experience on hot runner production of temperature controller;
500 square meter factory with hundreds of skillful workers;
Production ability is over 2000 piece monthly.
OEM/ODM orders are both welcomed!
