Shopping carry paper bag making machine/Automatic Brown Kraft Paper Bag Making Machine/stand up pouches bag production line / square bottom paper bag making machine/hand paper bag making machine Skype:kaiserzy
Product Description
The machine can produce the square bottom paper bag in conjunction with overseas advanced technology. The machine has many advantages such as high speed, high productive efficiency and wide-range adjustment. Automatic raw material feeding, automatic errors correct system and tension control, all these operational procedures are controlled by PLC. This is ideal equipment for producing various kinds of paper bags such as food paper bags, cosmetics handle paper bags, etc.
Characteristics:
1. Equipped with servo system with photocell for correction, tracking the printed material accuracy.
2. The electric control system promotes high speed, high precision motion control and production line. It detects automatically effect of integration and optical fiber.
3. The touch screen display simplifies machine operation.
4. The glue applicator system helps to move automatically as machine running<
5. Automatic fault detector and self diagnosis system reduce the chances to damage machine.
| Bag width | 3-7.5 inch | 76-191mm |
| Bottom width | 1.75-4 inch | 45-102mm |
| Bag length | 7.5-14.625 inch | 191-371mm |
| Max roll paper width | 23.75 inch | 603mm |
| Speed | 200 pcs/min | |
| Paper thickness | 45-120gsm | |
| Max feeding roll diameter | 55inch | 1, 400mm |
| Main motor | 10HP | 10KVA |
| Air compressor | 100PSI | 690KPA |
| Weight |
3500KG |
|
