QH11D Series Truecut Mechanical Shearing Machine
Features
The Motor driven mechanical shearing machine adopts the England desi QH11D True-cut Mechanical Shearing Machine, also named Electro Precision Plate Shear is specially used for thin plate sheets.
- This machine is different from the traditional driving method of mechanical shears.
- It is one of the most advanced miniature mechanical precision shear, and enjoys good reputation both at home and abroad.
- gn -- as brake motor driving though the shaft-mounted speed reduction unit for safety & low noise operation.
- The low cutting angle and inclined shear direction reduces bowing and twist to a minimum. Blade clearance is easily set by a manually operated quick set device.
- It’s an ideal true-cut machining equipment of metal sheet and nonferrous metal sheet
Main parameters of QH11D mechanical shearing machine
Model |
QH11D- 2.5x1250 |
QH11D- 2.5x1300
|
QH11D- 2.5x1500 |
QH11D- 2.5x1800 |
QH11D- 2.5x2000 |
QH11D- 2.5x2500 |
QH11D- 2.5x3050 |
Max. Shearing Thickness(mm) |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
2.5 |
Max. Shearing Width(mm) |
1250 |
1300 |
1500 |
1800 |
2000 |
2500 |
3050 |
Shear Angle |
1º30′ |
1º30′ |
1º30′ |
1º20′ |
1º30′ |
1º20′ |
1º30′ |
Number of Stroke(min-1) |
47 |
47 |
47 |
47 |
47 |
47 |
47 |
Back gauge(mm) |
0-650 |
0-650 |
0-650 |
0-650 |
0-650 |
0-650 |
0-650 |
Height of worktable(mm) |
800 |
800 |
800 |
800 |
800 |
800 |
800 |
Motor Power(kw) |
5.5 |
5.5 |
5.5 |
5.5 |
7.5 |
7.5 |
11 |
Net Weight(kg) |
1450 |
1500 |
1650 |
1700 |
1800 |
2080 |
3600 |
