QH11D-2.5x3000 Series mechanical shearing machine
- 100 Piece / Pieces per Month
- Shanghai China
- T/T L/C D/P D/A Credit Card PayPal
-
Omax Maxiem Pump Minor Maint 302700 Retainer Man 301873 301353 Ring Seal 303274 Major Maintenance Kit
-
Dual Port Swivels Seal Replacement Kit 308616 Package for Omax 308620-1 2 3
-
60KPSI SL-IV SL-V WK000216 05007786 Bushing Retainer Flange for KMT Water Jet Cutting
-
Waterjet Spare Parts 90K WK000190 189 20468617 20475871 Pneumatic Dump Valve
-
1-14493 UHP 90 degree 1/4 in. 94k Waterjet Repair Kit 015093-1 Swivel Rebuild Kit for Water Jet Cutt
-
Hydraulic Waste Car Body Shell Gantry Shear Machine for Scrap Recycling Center
Product Details
| Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | LIWANG |
| Model Number: | QH11D-2.5X3000 | Voltage: | as per request | Rated Power: | 11kw |
| Dimension(L*W*H): | according to per machine | Weight: | 2700KG | Certification: | ISO |
| Warranty: | 14 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
QH11D SERIES Mechanical shearing machine, Mechanical guillotine shearing machine
Main parameters
Model | Shearing thickness (mm) | Shearing width (mm) | Number of strokes | Backgauge range | Shearing angle (º) | Working table height (mm) | Main power (kw) |
QH11D-2.5X1250 | 0.7-2.5 | 1250 | 47 | 0-650 | 1.5 | 800 | 5.5 |
QH11D-2.5X1300 | 0.7-2.5 | 1300 | 47 | 0-650 | 1.5 | 800 | 5.5 |
QH11D-2.5X1500 | 0.7-2.5 | 1500 | 47 | 0-650 | 1.5 | 800 | 5.5 |
QH11D-2.5X1600 | 0.7-2.5 | 1600 | 47 | 0-650 | 1.5 | 800 | 5.5 |
QH11D-2.5X1800 | 0.7-2.5 | 1800 | 47 | 0-650 | 1.5 | 800 | 5.5 |
QH11D-2.5X2000 | 0.7-2.5 | 2000 | 47 | 0-650 | 1.5 | 800 | 7.5 |
QH11D-2.5X2500 | 0.7-2.5 | 2500 | 47 | 0-650 | 1.5 | 800 | 7.5 |
QH11D-2.5X3000 | 0.7-2.5 | 3050 | 47 | 0-650 | 1.5 | 800 | 7.5 |
Advantages of series QH11D shearing machine
Scale on backgauge
Exports of spare parts
