Economical Automatic Screen Printing Machine for Automotive Glass

Economical Automatic Screen Printing Machine for Automotive Glass thumbnail-1
Economical Automatic Screen Printing Machine for Automotive Glass photo-1
US$ 20,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Other, Glass Printing Machine, Glass Printing Machine
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Haining Lidu Glass Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Other, Glass Printing Machine, Glass Printing Machine
Place of Origin Zhejiang, China
Brand Name LIDU
Model Number LDSJ1600
Voltage 380V
Power(W) 2.5Kw
Dimension(L*W*H) 4100*2300*1500mm
Weight 3.5t
Certification Other, CE, ISO9001:2000
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

screen printing machine
1.automatic positioning glass
2.easy operation
3.reliable performance
4.CE certificate

Automatic Screen Printing Machine for automotive glass

 Economical Automatic screen printing machine for automotive glass

Usage and Performance of  Automatic Screen Printing Machine for automotive glass

Usage: This machine can be used for Screen Printing of mist glass and concaved mist glass.

Performance: a semiautomatic machine both electrical control and gas control was used, with hand feeding and baiting. Simple operation, low cost and low power.

-------------------------------------------------------------------------------------------------------

Working Principle of  Automatic Screen Printing Machine for automotive glass

According to the need of production technology, Mengsa cream, protection printing ink or other chemical materials can be printed uniformly on glass through the screen by 1# and 2# scrapers, and the glass would be protected or mist.

-------------------------------------------------------------------------------------------------------

Installation and Debugging of Automatic Screen Printing Machine for automotive glass

1) An air compressor with capacity of 0.2-0.3 m3/min should be additionally used, and the air pressure should be controlled between 4 to 8 kg/cm2.

2) Adjust the platform carrier to horizontal with deviation less than 0.1mm/m, the extension track <3> of platform carrier must be connected to the device by screw bolt, and the carrier should be moved flexibly.

3) The working range of the air pressure meter on the electrical control cabinet must be between 2 to 4 kg/cm2.

4) Air pressure when scrapers operating must be controlled at 2-2.5kg/cm2.

5) Move the scrapers stand to the direction indicated by the electrical control cabinet, and stop the stand at the side near the cabinet.

---------------------------------------------------------------------------------------------------------------------

Technical parameters of Automatic Screen Printing Machine for automotive glass :

Model

Max.Glass Size(mm)

Min.Glass Size(mm)

Max.Screen Size(mm)

Printing Table Size(mm)

Glass Thickness

(mm)

Power

(kw)

Weight

(T)

Machine Size(mm)

LDSZ2012

2000×1200

600×500

2800×1600

2450×1550

2.5-19

10

3.5

7200×2500×1300

LDSZ2519

2500×1900

700×500

3280×1800

3050×1600

2.5-19

12

4.3

8000×2500×1300

LDSZ2613

2600×1300

700×500

3380×1900

3050×1650

2.5-19

12.5

4.6

8220×2500×1300

LDSZ2617

2600×1700

700×500

3380×2300

3050×2050

2.5-19

12.5

5.1

9420×2500×1300

LDSZ3020

3000×2000

800×600

3780×2600

3450×2350

3-19

13.2

6.1

10620×2800×1300

LDSZ3725

3700×2500

1000×700

4380×3000

4050×2750

3-19

15.2

7.3

12420×3200×1300

LDSZ4525

4500×2500

1200×900

5280×3000

4950×2750

3-19

18.5

8.2

15120×3200×1300



Economical Automatic screen printing machine for automotive glass

 Final products of Automatic Screen Printing Machine for automotive glass

OUR SERVICE

 Your inquiry related to our product & price will be replied within 24hours.

 Well-trained & experienced staff are to answer all your inquiries in English of course.

 Working time: 9:00am - 6:00pm, Monday to Friday (UTC+8).

 OEM & ODM projects are highly welcomed. We have strong R&D team here to help.

 Your business relationship with us will be confidential to any third party.

 Good after-sale service offered, please get back if you got question.

 For more details, please feel free to contact us. We will be more than happy to help in anyway we can.

Why choose us

1. We’re manufacturer, which have specialized in the line for many years.

2. We could pick you up to visit our factory,

3. Best after-sale service.

4. Competitive price, high quality and quick delivery for long business.
