Automatic Glass Printing Equipment Glass Screen Printing Machine Quality Choice

Automatic Glass Printing Equipment Glass Screen Printing Machine Quality Choice photo-1
US$ 10,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
LIDU
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Zhejiang, China
Brand Name LIDU
Model Number LDSZ2613
Usage Other, glass printing
Automatic Grade Automatic
Voltage 380V
Gross Power 12.5kw
Dimensions(L*W*H) 8220*2100*1300mm
Weight 4.6t
Certification CE ISO, ISO9001:2000
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

glass screen printing machine
1.reasonable structure
2.aotomatic positioning glass
3.easy operation
4.reliable performance

 Economical glass printing equipment glass screen printing machine

Automatic glass printing equipment glass screen printing machine



General introduction of Economical glass printing equipment Glass Screen Printing Machine



Screen printing machine is a machine use printing technique to make colorful glass. It is widely used in decorative glass, architectural glass, furniture glass, appliance glass etc.

-------------------------------------------------------------------------------------------------------

Working Principle of Economical glass printing equipment Glass Screen Printing Machine

Screen printing machine uses a woven mesh to support an ink-blocking stencil to receive a desired image. The attached stencil forms open areas of mesh that transfer ink or other printable materials which can be pressed through the mesh as a sharp-edged image onto a substrate. A fill blade or squeegee is moved across the screen stencil, forcing or pumping ink into the mesh openings for transfer by capillary action during the squeegee stroke. Basically, it is the process of using a stencil to apply ink onto another material such as glass, ceramics, paper etc that can keep the image onto its surface.

-------------------------------------------------------------------------------------------------------

Technical parameters of Economical glass printing equipment Glass Screen Printing Machine:

Model

Max.Glass Size(mm)

Min.Glass Size(mm)

Max.Screen Size(mm)

Printing Table Size(mm)

Glass Thickness

(mm)

Power

(kw)

Weight

(T)

Machine Size(mm)

LDSZ2012

2000×1200

600×500

2800×1600

2450×1550

2.5-19

10

3.5

7200×2500×1300

LDSZ2519

2500×1900

700×500

3280×1800

3050×1600

2.5-19

12

4.3

8000×2500×1300

LDSZ2613

2600×1300

700×500

3380×1900

3050×1650

2.5-19

12.5

4.6

8220×2500×1300

LDSZ2617

2600×1700

700×500

3380×2300

3050×2050

2.5-19

12.5

5.1

9420×2500×1300

LDSZ3020

3000×2000

800×600

3780×2600

3450×2350

3-19

13.2

6.1

10620×2800×1300

LDSZ3725

3700×2500

1000×700

4380×3000

4050×2750

3-19

15.2

7.3

12420×3200×1300

LDSZ4525

4500×2500

1200×900

5280×3000

4950×2750

3-19

18.5

8.2

15120×3200×1300

 Final product of Economical glass printing equipment Glss creen Printing Machine

Automatic glass printing equipment glass screen printing machine
