Specifications
glass cutting machine1.easy operation
2.high processing precision and low noise
3.best after sales service
4.CE certificate
Auto cutting CNC glass cutting machine LDCJ3825
Brief introduction of Glass Cutting Machine:
This machine can do the beeline and shape cutting on flat glass. It adopts AC servo or stepping motor to synchronously drive axis X, Y and Z. The cutting precision can be guaranteed through the whole processing procedure. It is controlled by computer.Its features are: easy operation, moderate price and convenient maintenance.
-----------------------------------------------------------------------------------------------------
Main features of Glass Cutting Machine:
1.The machine can carry out any kind of straight, diagonal or shape cutting precisely and fully automatically.
2. Sensor for glass presence verification to avoid damaging the cutting head should the glass sheet be absent, broken or badly positioned.
3. Structure optima: The equipment is made of welded steel pipes, body structure is designed and analyzed completely, which support to reach to the best situation. The sheet is made by 200mm space to ensure that the table sets never deformation.
4. High precise cutting shaft, plastic and metal cutting wheel are both used together, glass thickness from 3 mm to 19mm, taper shape is mechanical fuse the special design for protection the cutting head.
-------------------------------------------------------------------------------------------------------
Technical parameters of Glass Cutting Machine:
Model |
Max.Glass Size(mm) |
Glass Thickness (mm) |
Rotating Angle(°) |
Max.Cutting Speed (m/min) |
Cutting Accuracy (mm) |
Air Pressure (mpa) |
Power (kw) |
Machine Size(mm) |
Weight (t) |
LDCJP0808 |
800 x 800 |
3 ~ 19 |
0 ~ 360 |
30 ~ 60 |
±0.35 |
0.5 |
2 |
1300 x 1300 |
0.8 |
LDCJP1212 |
1200 x 1200 |
3 ~ 19 |
0 ~ 360 |
30 ~ 60 |
±0.35 |
0.5 |
2.5 |
1700 x 1700 |
1.1 |
LDCJP1512 |
1500 x 1200 |
3 ~ 19 |
0 ~ 360 |
30 ~ 60 |
±0.35 |
0.5 |
3 |
2000 x 1700 |
1.4 |
LDCJP2015 |
2000 x 1500 |
3 ~ 19 |
0 ~ 360 |
30 ~ 60 |
±0.35 |
0.5 |
3.5 |
2500 x 2000 |
1.7 |
LDCJP3020 |
3000 x 2000 |
3 ~ 19 |
0 ~ 360 |
30 ~ 60 |
±0.35 |
0.5 |
4 |
3500 x 2500 |
2 |
