Double Straight-line Glass Edging Machine

Double Straight-line Glass Edging Machine thumbnail-1
Double Straight-line Glass Edging Machine photo-1
US$ 10,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Glass Edging Machine
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Haining Lidu Glass Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Glass Edging Machine
Place of Origin Zhejiang, China
Brand Name LIDU
Model Number LSZM250020
Voltage 380V
Power(W) 50Kw
Dimension(L*W*H) 5800X4400X2100
Weight 6.5t
Certification Other, CE, CE/ISO9001:2000
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Glass edging machine
1.smooth transmission system
2.advanced configuration control
3.super size processing
4.CE &ISO

Double Straight-line Glass Edging Machine

Double Straight-line Glass Edging Machine in the factory



 Brief introduction of Double Straight-line Glass Edging Machine :

The machine with 20-26 grinding heads is suitable for grinding the double straight-line of flat glass. Rough grinding, fine grinding,polishing can be done at one time.Gliding of grinding head holder adopts double straight line rolling glide. Double ball screw rod transmission stabilizes moving speed and eliminates moving gap, reduces resistance and wear out, and ensures repeated positioning. PLC control system sets processing parameters via interface, and finishes processing at one time.Polishing grinding head combines pneumatic machinery and lock control, and can be operated independently.



The product has stable structure, precise and smooth transmission system,advanced configuration control system and super size processing capacity, suitable for processing glass for home furniture and architecture.

-------------------------------------------------------------------------------------------------------

Double Straight-line Glass Edging Machine

Delivery site of Double Straight-line Glass Edging Machine



Application of Double Straight-line Glass Edging Machine :

This machine is used for grinding the parallel straight lines of the flat glass of different size and thickness from 2 to 19 mm. Also it can process the chamfer at 45º of the straight edge and grind the four angles.

------------------------------------------------------------------------------------------------------

Main features of Double Straight-line Glass Edging Machine:



1. This machine consists of 8 parts: main body, fixed grinding head rack, movable grinding head rack, pressing conveying belt, feeding positioning rack, unloading rack, electric cabinet and water tank.



2. Its body is processed by grinding, which is with high precision. There is a protection shroud to avoid dust and water.



3. Customers can choose the quantity of the rough grinding, fine grinding and polishing heads according to grinding quality.

-------------------------------------------------------------------------------------------------------



Technical parameters of Double-edging Machine:



Model

Grinding Head

(PCS)

Glass Width

(mm)

Glass Thickness(mm)

Chamfer Width

(mm)

Machine Size

(mm)

Max.Grinding Quantum

(mm)

Conveying Speed

(m/min)

Compressed Air

(kg/cm2)

Power

(kw)

Weight

(t)

LDZM2500-20

20

250-2500

3-25

1-3

5800×4400×2100

5

0.5-5

4-8

50

6.5

LDZM3000-22

22

250-3000

3-30

1-3

6300×5000×2100

5

0.5-5

4-8

53

7.3

LDZM4000-26

26

250-4000

3-30

1-3

7300×5800×2100

5

0.5-5

4-8

62.5

8.0
