Hot sale charcoa briquette making
machine
Introduction of the charcoal briquette making machine:
* The raw material of the charcoal briquette making machine could be sawdust, crop straw, wood branches, rice hull, bamboo sawdust,peanut/
sunflower shell, furfural dregs, cotton/corn stalks, sesame straw, corncob and broken branches;
* The charcoal briquette making machine can make stick shape wood briquette of different diameter and different shape;
* This screw charcoal briquette making machine is equipped with automatic temperature control system,which is designed to produce high density wood briquette from biomass.
* The motor can be 11kw/15kw/18.5kw/22kw-3phase-380v-50hz electrical driven motor. This machine can be operated 16 hours per day.
* The finished briquette can be used as fuel for briquette boilers or boilers for heating.
Features of the charcoal briquette making machine
1. The diameter of the briquette: 50-80mm normally.
2.Type: ZBJ-I, ZBJ-II
3. Capacity: 150-400kg/h
4. You can choose one briquette machine, or briqutte machine plant.
5. Raw material: Agriculture waster: straw waster, wood dust, others
Model |
AMS-ZBJ-I |
AMS-ZBJ-II |
Motor (kw) |
15kw, 380V/60Hz |
18.5kw, 380V/60Hz |
Diameter of the briquettes: |
Ø 50mm |
Ø 70mm,Ø 80mm |
Capacity |
160-200kg/h |
350-400 kg/h |
Weight (kg) |
600kg |
750kg |
Dimensions(mm) |
1500*600*1600 |
1850*650*1300 |
Product images of the charcoal briquette making machine :
The spare parts of the charcoal briquette making Machine
The charcoal Briquette making machine plant
1. Crusher: Crush the raw material into small pieces (diameter is about 3-5mm)
2. Dryer: Dry the material by machine or dried it in the sun , till the moisture is less than 12%
3. Put the material into feed let of briquette machine
4. Produce the briquette stick from biomass material without any additive
5. Carbonized the briquette stick
Final briquettes of the charcoal briquette making machine
After the processing of drying, compressing under the high pressure and temperature, the biomass briquette is characterized by high density, small in size, better combustion, capable as the substitute for the superior coal or firewood. This bio-fuel briquette is 50-80mm in diameter, occurs in the hollow quadrangular or hexagonal cylinder with a 15-20mm hole through the body.
The packing and delivery of the charcoal briquette making machine
