RO Membrane
US$ 2.2 - 2.55
MOQ: 100 Rolls
Key Specifications
Get Latest Price
Type:
Reverse Osmosis
Use:
Household Pre-Filtration
Certification:
Other, certified by the International Certification Network
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Reverse Osmosis
Use
Household Pre-Filtration
Certification
Other, certified by the International Certification Network
Place of Origin
Shandong, China
Brand Name
Jozzon
Model Number
Enhanced Fouling Resistant (FR) Series
The surface of FR series membrane elements has the characteristics of lower roughness and higher hydrophilism. Based on all series of RO membrane including brackish water, sea water and running water, Jozzon has developed FR technology with the advantages of reducing the colloid fouling, organics and fouling and advancing the cleaning recovery performance. The inlet conduit with the special inlet angle of 34mil-36mil enhances the fouling resistant performance and effective cleaning to maintain system in the low pressure drop under high-pollution condition.
Introduction
Jozzon fouling resistant (FR) series have the advantages of high flux and desalination to be suitable for surface water, underground water, running water and municipal water with salinity of 7000ppm. FR series are mainly applied for industrial water treatment including reuse of reclaimed water and boiler feed water of power station, especially for treatment of industrial effluent with little organic pollutants, municipal sewage and micropollution water.
Specification and Main Performance of Membrane Elements
Model |
Active Membrane Area ft2(m2) |
Average Permeated Flow GPD(m3/d) |
Stable Rejection Rate (%) |
Minimum Rejection Rate (%) |
JBW8040-365/34-FR |
365(33.9) |
9000(34.1) |
99.5 |
99.3 |
JBW8040-380/34-FR |
380(35.3) |
9500(36.0) |
99.5 |
99.3 |
JBW8040-400/34-FR |
400(37.2) |
10000(37.9) |
99.5 |
99.3 |
JBW-4040-FR |
90(8.4) |
2200(8.3) |
99.5 |
99.3 |
Testing Conditions
Testing Pressure……………………………………………….. 225psi (1.55Mpa).
Temperature of Testing Solution……………………………. 25℃
Concentration of Testing Solution (NaCl)………………… 2000ppm
pH Value of Testing Solution………………………………….. 7.5
Recovery Rate of Single Membrane Element………………. 15%
Operation Limits and Conditions
Max. Working Pressure…………………………………………. 600psi(4.14Mpa)
Max. Feedwater Flow……………………………………………. 75gpm(17m3/h) (8040)
16gpm(3.6m3/h) (4040)
Max. Feedwater Temperature……………………………………. 45℃
Max. Feedwater SDI15…………………………………………….. 5
Residual Chlorine Concentration of Feedwater………………….<0.1ppm
pH Range of Feedwater during Continuous Operation…………3~10
PH Range of Feedwater during Chemical Cleaning……………2~12
The Max. pPressure Drop of a Single Membrane Element ......... 15psi(0.1Mpa)
