RO Membrane
US$ 2.2 - 2.75
MOQ: 100 Rolls
Key Specifications
Get Latest Price
Type:
Reverse Osmosis
Use:
Household Pre-Filtration
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Reverse Osmosis
Use
Household Pre-Filtration
Place of Origin
Shandong, China
Brand Name
Jozzon
Model Number
Brackish Water (BW) Series
Introduction
Jozzon RW series RO membrane elements include high desalination series and high flow series. RW series are suitable for desalination of surface water, underground water and low pollution water source with TDS<1500ppm. RW series are mainly applied for municipal landscape and agricultural irrigation, drinking water treatment, municipal water supply, dewatering and reclaimed water treatment, water purification system in pharmaceuticals industry, business water purifier, water purifier system in hospital and laboratory and integrated water purifier with the advantages of lower operation pressure, higher flow and lower energy consumption.
Specification and Main Performance of Membrane ElementsTesting
|
Model
|
Active Membrane Area ft2(m2) |
Average Permeated Flow GPD(m3/d) |
Stable Rejection Rate(%) |
Minimum Rejection Rate(%) |
JRW-8040 |
400(37.2) |
11000(41.6) |
99.0 |
98.0 |
JRW8040-400-HF |
400(37.2) |
12500(47.4) |
99.0 |
98.0 |
JRW8040-400-HR |
400(37.2) |
11500(43.6) |
99.4 |
99.0 |
JRW-8040-430 |
430(40.0) |
13200(49.9) |
99.0 |
98.0 |
JRW-4040 |
90(8.4) |
2500(9.5) |
99.0 |
98.5 |
JRW-4040-HR |
90(8.4) |
2300 (8.7) |
99.4 |
99.0 |
JLE-4040 |
92(8.6) |
3000(11.3) |
98.5 |
98.0 |
JRW-4021 |
38(3.5) |
1000(3.78) |
99.0 |
98.0 |
JRW -2521 |
14(1.3) |
300 (1.13) |
99.0 |
98.0 |
JRW -2540 |
28(2.6) |
750 (2.84) |
99.0 |
98.0 |
Conditions:
Testing Pressure………………………………………………… 150psi (1.03Mpa)
Temperature of Testing Solution………………………………. 25℃
Concentration of Testing Solution (NaCl)………………………1500ppm
pH Value of Testing Solution………………………………….….. 7.5
Recovery Rate of Single Membrane Element………………… 15%,8%(4021 and 25Series)
Operation Limits and Conditions
Max. Working Pressure……………………………………….. 600psi(4.14Mpa)
Max. Feedwater Flow………………………………………….. 75gpm(17m3/h) (8040)
16gpm(3.6m3/h) (4040,4021)
6.0gpm(1.4m3/h) (2521,2540)
Max. Feedwater Temperature…………………………………45℃
Max. Feedwater SDI15………………………………………….5
Residual Chlorine Concentration of Feedwater………………<0.1ppm
pH Range of Feedwater during Continuous Operation………3~10
PH Range of Feedwater during Chemical Cleaning……………2~12
The Max. Pressure Drop of a Single Membrane Element ..... 15psi(0.1Mpa)
