Help CenterSZFM-1100 Automatic Water-base Laminating Machine
Related Products
-
Main Technical Variables SRFM-720 SRFM-1020 SRFM-1200 SRFM-1400 SRFM -1600US$ 15,000 - 17,500MOQ: 1 Set -
PCM560 Hard Cover Book Pressing & Creasing MachineUS$ 15,000 - 17,500MOQ: 1 Set
-
YFMB-720A/920A/1100A/1400A Semi-automatic Glueless Laminating MachineUS$ 15,000 - 17,500MOQ: 1 Set
-
LPM-400 Label Punching MachineUS$ 15,000 - 17,500MOQ: 1 Set
-
SGUV-420/520/650 Small UV CoaterUS$ 15,000 - 17,500MOQ: 1 Set
Features:
The machine uses conservational water-base glue and BOPP film or PET film to laminate printed paper. The laminated products have the features of clear picture and good spatial effect etc. It is widely applied for the lamination of books, wall calendar, hand bag, wine packing box etc.
Configuration:
1.To adapt schneider frenquency converter to adjusted working speed stably and easily.
2.Automatic document feeder FeiDa the improve work efficiency.
3.Dip coating saves glue and homogenizes coating much better.
4.Film cutter cuts film width to make it meet paper size. The cut film is left on the film release spindle.
5.Automatic paper winder rolls up laminated paper. winding speed is adjustable upon applications.
6.Phillip IR drying lamp is equipped for smoot working in humid and cold climate.
7.No paper protector stops the machine’s running when no paper occurs in paper conveying.
8.The winded paper is supported by a trolley, and then put on cutting machine for automatic cutting, or cut by manual
Technical Parameter:
| Model | SZFM-1100 |
| Max laminating size | 1040*780mm |
| Min laminating size | 350*440mm |
| Max speed | 60m/min |
| Paper weight | 80-400g |
| Power | 8KW |
| Total Weight | 2000kg |
| Overall Dimensions | 3800*1750*1700mm |
