Help CenterYGFM-1100A Fully Automatic Laminating
Related Products
-
SGUV-650C/1000C/1200C UV Coating MachineUS$ 15,000 - 17,500MOQ: 1 Set -
SCM500A Semi Auto Case-makerUS$ 15,000 - 17,500MOQ: 1 Set
-
SZFM-1100 Automatic Water-base Laminating MachineUS$ 15,000 - 17,500MOQ: 1 Set
-
Main Technical Variables SRFM-720 SRFM-1020 SRFM-1200 SRFM-1400 SRFM -1600US$ 15,000 - 17,500MOQ: 1 Set
-
PCM560 Hard Cover Book Pressing & Creasing MachineUS$ 15,000 - 17,500MOQ: 1 Set
Specifications
UV Coating MachineUV Varnishing Glazing Machine
Configuration:
1.Automatic paper feeder adopts oil-free vacuum pump to feed paper automatically. and paper can be added even if the machine is kept running, which improves working efficiency so much.
2.Man-machine interface system: color tuch screen simplifies the maching operation. on the touch screen, as long as the operator inputs paper size, overlap length and working speed etc., the machine can realize completely automated operation. and on touch screen, working status of the machine can be checked at any time.
3.Automatic paper feeding system is equipped with no paper protector, paper break protector and paper superposing protector, which are controlled by photoelectric and mechanical systems. when no paper, paper break or paper super position occurs, the machine will stop automatically for self-protection.
4.Conveying table is furnished with air aspirator and front lay etc. to regulate page conveying and overlap and improve lamination prevision.
5.High precision of big chrome plated heating roller is equipped with built-in oil heating system, which has excellent performance to temperature control. The laminating temperature is adjustable upon applications.
6.Hydraulic pressuring system provides automatically big and steady pressure to guarantee good laminating quality.
7.Air expansion shaft releases film, and perfects the precision of film release, and also makes the loading and unloading offilm roll much more convenient.
8.The combination of air expansion shaft and braking device can adjust film release tension and release speed.
9.Pneumatic cutting system realizes automatic paper cut as long as the operator inputs the size of workable paper on the tuch screen.
10.Collecting unit is furnished with corrugating paper pressing system, which settles completely the crimping trouble of thin and big size of laminated paper.
Technical Parameter:
| Model | YGFM-1100A |
| Max paper size | 1100*1200mm |
| Min paper size | 300*300mm |
| Laminating speed | 0-50m/min |
| Paper weight | 100-500g |
| Power | 30KW |
| Total Weight | 5000kg |
| Overall Dimensions | 9000*2260*1900mm |
