Configuration:
1.adopping automatic feeder, so that the feeding ,laminating ,separating can totally inline for laminating job.
2.the overlap use servo –motor control , when operating the machine just need to set the paper length on touch screen, the machine can run automaticlly , the overlap tolerance is about ±2mm.
3.the heating roller is use heat transfer oil, the temprature meter is inside the oil, not touch with the roller surface, so that get the accurate temprature.
4.Adop the jogger for collecting the paper, after pneumatic separating paper can collect well with the vibrating table ,no need extra people for collection.
5.use pneumatic pressure, and can get bigger pressure ,and easier for usual maintance.
6.the main electrical prodcuts use import and taiwan produce, to make sure the stable for running the machine.
7.use the anti-curve for thin paper, make sure the thin paper after laminating is not decline and difficult for paper collection.
8.the film loading is using the air shaft ,easy loading , the film feeding use pneumatic brake blocked, have very stable tension.
Technical Parameter:
| Model | YFMA-520 |
| Max laminating size | 540*760mm |
| Min laminating size | 240*290mm |
| Max speed | 30m/min |
| Laminating temprature | normal-130°C |
| Paper weight | 127-450g |
| Power | 11KW |
| Total Weight | 1000kg |
| Overall Dimensions | 3000*1450*1650mm |
