Home > Manufacturing & Processing Machinery > Paper Machinery > Paper Making Machine > YFMA-650/800 Automatic Laminating Machine
YFMA-650/800 Automatic Laminating Machine
US$ 15,000 - 17,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Laminating Machine
Computerized:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
YFML-520 Semi-auto LaminatorUS$ 15,000 - 17,500MOQ: 1 Set -
Hard Cover Case in MachineUS$ 15,000 - 17,500MOQ: 1 Set
-
SHH-AG Pre-folder&Lock Bottom Automatic Folder GluerUS$ 15,000 - 17,500MOQ: 1 Set
-
RS LAMINATING MACHINEUS$ 15,000 - 17,500MOQ: 1 Set
-
RW LAMINATING MACHINEUS$ 15,000 - 17,500MOQ: 1 Set
Condition
New
Type
Laminating Machine
Computerized
Yes
Place of Origin
Shanghai, China
Brand Name
GAOHE
Model Number
GH-1000CC
Voltage
380VAC
Power(W)
16KW
Dimension(L*W*H)
6620*1575*1500mm
Weight
2000KGS
Warranty
1 YEAR
After-sales Service Provided
Engineers available to service machinery overseas
vApplications:
Tosuit two kinds of film:pre-glued film and glueless film
Configuration:
1.Stream feeder, with automatic sheeting and jogger delivery.
2.Oil free vacuum pump on stream feeder with both separating and forwarding suckers.
3.Servo-controlled pump on stream feeder with both separating and forwarding sucker.
4.Oil heated for stable and precise PID electronic control of temprature
5.Film slitting and perforating system on feed roll.
6.Sheet decurling device for production of flat laminated sheets.
7.Strong pneumatic laminating pressure.
8.Pneumatic film tension brake.
9.Swing-away film loading onto airshaft.
10.Whole machine is easily moved by pallet trolly for convenient storage in limited spaces.
Technical Parameter:
| Model | YFMA-650 | YFMA-800 |
| Max laminating size | 650×880mm | 780×1040mm |
| Min laminating size | 290×290mm | 290×290mm |
| Max speed | 35m/min | 35m/min |
| Laminating temprature | normal-130°C | normal-130°C |
| Paper weight | 127-450g | 127-450g |
| Power | 13KW | 15KW |
| Total Weight | 1200kg | 1500kg |
| Overall Dimensions | 3200×1550×1650mm | 4000×1850×1650mm |
