Road Marking Machineis suitable for marking lines on the plastic running tracks or artificial lawns
Road Marking Machine
1.Machine introduction:
The Line Marking Machine is suitable for marking lines on the plastic running tracks or artificial lawns.
1.Airless spraying paining technology for which the high-pressure pump is drivenby a gasoline engine as been adopted in the line marking machine to create clear,smooth, saturating and even limes, providing a high working efficiency;
2.Both sides of the spraying gun are equipped with a limiting disc plates, ensuringthe line free of raw edges, such plates may be lift through a pulling line insteering, turning flexibly;
3.The spraying gun may be conveniently dismantle different nozzles and control theline width, suitable for common airless spraying for marking or labels;
4.It runs by pushing,with convenient turning ,reliable orientation and flexible turning.
2.Technical parameters:
Working Pressure |
12 Mpa (1700 psi) |
Marking Speed |
0.5-3 Km/h |
Flow Rate |
1.2 L/min |
Power |
2.2Kw |
Weight |
110kg |
External Dimension (L×W×H) |
1000mm×550mm×750mm |
3.Contact information:
