Paving Machine for Sports GroundIt's suitable for spreading and paving the bottom layer of plastic sporting venues.
Paving Machine for Sports Ground
1.Machine introduction:
It's suitable for spreading and paving the bottom layer of plastic sporting venues
(1).Used for spreading,paving the bottom layer of plastic sporting venues;
(2).Framework: with a firm and stable welded H-type structure, and a rust-proof paint layer,it may accommodate any poor condition in the construction site;
(3).Front scratch board:welded joint structure, the ground clearance is manually adjustable through a screw, which control the thickness of the floor layer.The width may be adjusted through a limiting board;
(4).Driving device: the main driving system is a motor-driven caterpillar chain,with the speed smoothly controlled by a frequency converter,which is feature as stably and precisely moving ahead or back in an motion.It may be equipped with different caterpillar belt for different bottoms;
(5).Walking Mechanism:the spreading machine may be manually moved or relocated through a walking mechanism consisting of a hydraulic cylinder and lift;
(6).Screed:The screed has four functions,viz.the adjustment of height,angle,temperature,and vibration. The plastic cement material is vibrated,compacted and paves while passing through the screed.
2.Technical Parameters:
Effective Working Width |
2500mm |
Moving Speed |
0.8 - 6m/min |
Paving Capacity |
100m2/h - 400m2/h |
Power |
8.6kw |
Weight |
850kg |
External Dimension (L×W×H) |
2750mm×1800mm×750mm |
