Desk Mini and small wave soldering machine
Control System
> PC control system with windows based control software.
>Lenovo Computer and Siemens PLC
Preheaters System—Patented Heating Plate
>4 independent heating modules (overall length:1.8m), each consists of patented
>Preheating zone with heating tube(3zone) and forced hot air convection(1zone) ensures the best flux activation temperature and activation time.
Distortion-free Conveyor System
>Chain type entrance guides.
>Enhanced titanium finger conveyor is of high elasticity and is distortion-free.
>The conveyor system is steady and safe with adjustable speed (100-2000mm/min).
>Automated finger cleaner ensures long finger life.
Spray Fluxer
>SMC cylinder(Stepper motor is option) driven spray fluxer for computer controlled model
>Specially designed air knife can prevent the flux from entering the preheating zone causing fire and remove excessive flux.
>Flux and air flow can be adjusted via the control panel.
Brand New Lead-free Solder Pot
>Brand new lead-free dual wave solder pot, temperature difference between the two waves is less than 30℃.
>Minimized solder oxidation, automated solder dross collection( patent technology).
>Optimized solderability for lead-free process.
Cooling System
>Standard Turbine blower.
|
ETA Lead Free Wave soldering machine Specifications | |||||||
Specifications |
C4 |
C3 |
C2 |
C1 |
|||
Dimension:L*W*H(mm) |
4200 X 1250 X 1500 |
3600 X 1250 X 1500 |
2100 X 900 X 1500 |
2000 X 1250 X 1500 |
|||
Weight(kg) |
Approx.2100kg |
Approx.1800kg |
Approx.1500kg |
Approx.900kg |
|||
Power Supply |
3P5W,380/220V 50Hz |
3P5W,380/220V 50Hz |
3P5W,380/220V 50Hz |
3P5W,380/220V 50Hz |
|||
Startup Power (kw) |
28kw |
24kw |
18kw |
15kw |
|||
Operation Power Consumption |
10kw |
8kw |
6kw |
4kw |
|||
Control System |
PLC |
PLC |
PLC |
PLC |
|||
Spray System |
|||||||
Transmission Methed |
Air cylinder/step motor(option) |
||||||
Spray Pressure |
0.25Mpa--0.4Mpa |
||||||
Flux flow |
10--100ml/min |
||||||
Exhaust Ducting Diameter |
Φ200mm |
||||||
Exhaust Capacity |
25m3/min |
||||||
Preheating System |
|||||||
ETA is the leading SMT factory solution provider in China,offering professional SMT factory building advice and service.We have 20 year experience about SMT factories,offering full solutions for global clients with our great advantaged sources.Our core technology team members are well experienced in SMT filed, learning experience from top international chip mounters meanwhile increasing independent research and development. Currently ETA SMT equipment is representative of high quality , has maintained absolute leading technology in the industry.
Over the years the company has been committed to improving technology, quality and perfect service. ETA makes a positive contribution to international standard,the annual total capacity of 1200 sets, passed the ISO9001: 2000, ISO14000, CE, UL, RoHS and other certifications. Full implementation of the IPD process, reliable design and testing throughout the entire product life cycle.ETA’s continued investment in research and development and great contribution has been unanimously recognized in the field. By the end of 2012, ETA has declared more than 30 patents and software copyrights (including four invention patents), and actively involved in a number of national and industry standards. ETA provides more advanced products and fast technical support for global customers, at home and abroad.
6 Zones /8 Zones Lead Free Reflow Oven for SMT Soldering
SMT/LED Semi-auto and full-auto Printer
LED Mounter Agent
Wave solding machine and line
After-sales service:
>Factory Warranty: One-year warranty factory service.
>Installation: On-site installation and commissioning, to ensure smooth production
>Technical Training: provides professional training from Level 1 to Level 3
