Desk Mini Wave Soldering Machine C2

US$ 5,000 - 12,000 MOQ: 1 Set

Key Specifications

Business Type:

Manufacturer, Trading Company, Agent

Year Established:

2012

Factory Size:

3,000-5,000 square meters

Shenzhen ETA Electronic Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

HONGKONG

Delivery Detail:

Delivery time depends on order quantity.

Desk Mini and small wave soldering machine C2

Control System

> PC control system with windows based control software.

>Lenovo Computer and Siemens PLC

Preheaters System—Patented Heating Plate

>4 independent heating modules (overall length:1.8m), each consists of patented

>Preheating zone with heating tube(3zone) and forced hot air convection(1zone) ensures the best flux activation temperature and activation time.

Distortion-free Conveyor System

>Chain type entrance guides.

>Enhanced titanium finger conveyor is of high elasticity and is distortion-free.

>The conveyor system is steady and safe with adjustable speed (100-2000mm/min).

>Automated finger cleaner ensures long finger life.

Spray Fluxer

>SMC cylinder(Stepper motor is option) driven spray fluxer for computer controlled model

>Specially designed air knife can prevent the flux from entering the preheating zone causing fire and remove excessive flux.

>Flux and air flow can be adjusted via the control panel.

Brand New Lead-free Solder Pot

>Brand new lead-free dual wave solder pot, temperature difference between the two waves is less than 30℃.

>Minimized solder oxidation, automated solder dross collection( patent technology).

>Optimized solderability for lead-free process.

Cooling System

>Standard Turbine blower.

ETA Lead Free Wave soldering machine Specifications
Specifications	C4	C3	C2	C1
Dimension:LWH(mm)	4200 X 1250 X 1500	3600 X 1250 X 1500	2100 X 900 X 1500	2000 X 1250 X 1500
Weight(kg)	Approx.2100kg	Approx.1800kg	Approx.1500kg	Approx.900kg
Power Supply	3P5W,380/220V 50Hz	3P5W,380/220V 50Hz	3P5W,380/220V 50Hz	3P5W,380/220V 50Hz
Startup Power (kw)	28kw	24kw	18kw	15kw
Operation Power Consumption	10kw	8kw	6kw	4kw
Control System	PLC	PLC	PLC	PLC
Spray System
Transmission Methed	Air cylinder/step motor(option)
Spray Pressure	0.25Mpa--0.4Mpa
Flux flow	10--100ml/min
Exhaust Ducting Diameter	Φ200mm
Exhaust Capacity	25m3/min
Preheating System
