Heat Pumps Air to Water High Temperature(CE, CB, EC, ETL, CETL, C-TICK, WATER MARK, STANDARD MARK, UL, SABS, SANS, SAA, SASO)

FOB Price

US$ 200 - 10,000 / Unit

5 Units(Min. Order)

Port Guangzhou China
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Air Source Heat Pump	Installation	Freestanding
Storage / Tankless	Storage	Housing Material	Other, Steel with Painting
Use	Bathroom	Certification	CB, CE, EMC, Other, SASO, UL, CB, CE, EMC, RoHS, SASO, UL, EC, ETL, CETL, C-TICK, WATER MARK, STANDARD MARK, SABS, SANS, SAA, VDE
Place of Origin	Guangdong, China	Brand Name	PHNIX
Model Number	PASHW008~200L/250L/300L

Product Description

Heat Pumps Air to Water High Temperature

This series of High Temperature Compact Bath Water Heaters are desighed to make domestic sanitary hot water. As a lovely equipment, it can be put in storage/garage or near the kitchen or the washing room. A lot of attention has been put on its appearance design. To make the whole unit small, the structure inside is also very compact and organized well.

FEATURES

1) Aluminium condensing coils outside the inner tank
2) R134a heating high efficiency compressor
3) Inner tank: SUS 304 stainless steel (INOX) or enameled tank
4) Various design: 80L/100L/120L/150L/ 200L/250L/300L avaliable
5) Electrical expansion valve and thermal expanision for option
6) Testing conditions are based on EN 16147 (EN255-3)
7) SUS 304 stainless steel flexible coils for solar heating collector --- for option
8) Auto-ventilation is for option

CERTIFICATIONS

CE, CB, EC, ETL, CETL, C-TICK, WATER MARK, STANDARD MARK, UL, SABS, SANS, SAA, SASO, VDE, RoHS, REACH, EN16147, EN255-3, Recs, Water Mark, Standard Mark, EF, FHR, ISO9001, ISO14001, Six Sigma, Lean Production and Management

High Temperature Compact Bath Water Heater
Model	PASHW	003-80LD	008-200LD	010-250LD	015-300LD
Heating Capacity	kW	1.0	1.8	2.3	3.2
	BTU/h	3400	6100	7800	10880
Power Supply	V/Ph/Hz	230V~/50Hz
COP	W/W	3.7	3.9	3.6	3.6
Water Tank Volume	L	80	200	250	300
Net Dimensions(D×H)	mm	Φ520×1160	Φ560×1705	Φ560×1956	Φ640×1945
Shipping Dimensions(L/W/H)	mm	710/640/1225	630/630/1740	630/630/2010	720/720/2020
Heating: Ambient temp.:15/13°C, Water temp from 15°C to 45°C; Energy efficiency test is based on Standard DINEN255-3-1997. The above data is for reference only; specific data is subject to the product nameplate.
