Home > Products > MPPT Solar charge controller > 80A MPPT solar charge controller 12V/24V/48V Economic design air cooling 2015 New Product
80A MPPT solar charge controller 12V/24V/48V Economic design air cooling 2015 New Product
USD $225 - $228
/ Carton
1 Carton(Min.Order)
- 0 per Month
- NINGBO
- Credit Card
You May Like
-
60A 12V/24V/48V MPPT Solar charge controller
-
30A MPPT solar charge controller 12V/24V/48V flexible air cooling IP54 design
-
2016 LP-B500W, AC220-224V, DC to AC solar inverter, car inverter, home inverter
-
500W, AC220-224V, DC to AC solar inverter, car inverter, home inverter
-
LP-B600W, AC220-224V, DC to AC solar inverter, car inverter, home inverter
-
LP-B400W, AC220-224V, DC to AC solar inverter, car inverter, home inverter
Product Details
| Place of Origin | Zhejiang, China | Brand Name | LEAP/SMK | |
| Model Number | SMK-SCH-80A | Application | Charger Controller | |
| Rated Voltage | Other, 12V/24V/24v | Maximum Current | 80A |
Product Description
| Model | SMK-SCH-70A | SMK-SCH-80A |
| Solar System Voltage | 12V/24V/36V/48V Auto work | |
| Electrical | ||
| PV Operating Voltage | 18~150Vdc@12V 35~150Vdc@24V 50~150Vdc@36V 60~150Vdc@48V | |
| MPPT voltage range | ||
| Max. PV input power | 12V 1000W | 12V 1200W |
| 24V 2000W | 24V 2300W | |
| 36V 3000W | 36V 3300W | |
| 48V 4000W | 48V 4600W | |
| Rated input current | 70A | 80A |
| Rated DC load current | 60A Adjustable(0A~60A) | |
| Self consumption | 2W | |
| Conversion Efficiency | 98.5% | |
| Protection | Over load, short circuit, over voltage,reverse protection | |
| Battery charging | ||
| Battery Type | Sealed Gel AGM Flooded Lithium | |
| Charge algorithm | 4 stage: Bulk, Absorption, Float, Equalize charging | |
| Bulk charge voltage | Sealed: 14.4V AGM 14.2V Gel:14.2V Flooded:14.6V User defined:10-15V | |
| Float charge voltage | Sealed/Gel/AGM:13.8V Flooded:13.7V User defined:10-15V | |
| Equalize charge voltage | Sealed 14.6V AGM:14.8V Flooded:14.9V | |
| Load disconnect voltage | 10.5V~12V adjustalbe | |
| Low voltage reconnect voltage | 12.5V | |
| Temperature compensation | 5mV/℃/2V with BTS | |
| Communication | ||
| Communication Port | RS485(Standard) Ethernet RS232 Optional with On line monitoring system | |
| Physical | ||
| Net weight | 7.7kg | |
| Gross weight | 8.7kg | |
| Dimension | 353*227*110MM | |
| Cooling | Air cooling | |
| Enclosure | IP54 | |
| Environment | ||
| Ambient operating temperature | -25℃~60℃ | |
| Storage Temperature | -40℃~80℃ | |
| Humidity | 100% non-condensing | |
| Warranty | Two years | |
| Technical data for 12V system at 25℃, twice in 24V system rate, triple in 36V System rate and quaduple in 48V system rate | ||
