Self-supporting Outdoor Fiber Optic Patch Cord
Specifications
Self-supporting Outdoor Fiber Optic Patch Cord1.ISO9001:2000
2..LDPE jacket
3..Feller mater
4..manufacturer
Self-supporting Outdoor Fiber Optic Patch Cord
Features:
a, Lower Insertion Loss
b, High Return Loss
c, Excellent Repeatability ,exchangeability, wearability and stability
d, Environmentally Stable
Application:
- Optical fiber communications system
-Telecommunication networks
-data processing networks
-Connection of optical transmission equipments and devices
-Computer network
- FTTX+LAN
-CATV
Characteristics
Optical | Jacket Machine | ||||||||
Test items | Units | Spec | Test items | Units | Spec | ||||
Single-mode fiber cutoff wavelength | λc/nm | ≤ 1250 | Test material | — | PVC | ||||
λcc/nm | ≤ 1260 | ||||||||
Maximum Attenuation @ | 1310nm | dB/km | ≤ 0.40 | Tensile Strength | Elongation at break | ||||
1550nm | dB/km | ≤ 0.30 | Thermal aging treatment | ||||||
Dispersion Coefficient | 1288-1339nm | ps/nm•km | |D|≤3.5 | Before | MPa/ % | ≥12.5 ≥150 | |||
1271-1360nm | Ps/nm•km | |D|≤5.3 | After | % | 20 ≥125 | ||||
1550nm | ps/nm•km | |D|≤18 | Time | h | 24×10 | ||||
Zero dispersion Wavelength | nm | 1300~1322 | Temperature | °C | 100±2 | ||||
Zero dispersion slope | ps/nm²×km | ≤0.092 | Change rate after heating aging | % | 20 | ||||
Light source continuity | — | continuous |
| ||||||
Others characteristics | Cable Net weight | 1Core | 22kg/km | ||||||
Product Length | m/Plywood Drum | 500 | 1000 | 2000 | |||||
Views of products
