1 core Selfregulated undetgroung infrared raychem Heating Tracing Cable

FOB Price

US$ 0.1 - 1 / Meter

500 Meters(Min. Order)

Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China	Brand Name	RX
Model Number	RX-RL/1R	Conductor Material	Copper
Insulation Material	Rubber	Jacket	PVC
Number of Conductors	1	Application	complex pipeline, long pipeline, instrument box

Product Description

Specifications

Temperature Uniform, Easy installation & maintenance, Energy save
Anti-explosion :No.CNEx05.1101X CJEx07.124U CNEx06.0205X

Technical parameters:

1,standard colors:Black .Grey

2,temperature range: Max maintenance temperature 65°C.

Max surface temperature 70°C±5°C.

Max bearing temperature 105°C.

3,Installation temperature:Min -60°C.

4,Thermo stability:Recycle 300 time from the temperature 10°C to 99°C,the heating value can keep 90% at least.

5,Bend radius:room temperature 20°C,the value is 25.4mm.room temperature −30°C,the value is 35.0mm.

6,Insulation resistance:when the length of heating cable is 100m,ambient temperature is 75°C,tested by 2500V DC tramegger 1 minute,the value of insulation resistance is 1200MΩ.

Working voltage:12V 24V 36V 110V 220V 380

Nominal power:10W/m 15W/m 20W/m 25W/m 35W/m 40W/m

Anti-explosion mark:ExellT4

Anti-explosion certificate of conformity:No.CNEx05.1101X CJEx07.124U CNEx06.0205X

Product advantages:

1,Electric heat tracing temperature uniform,no overheating,safe and reliable

2,Energy saving

3,Intermittent operating:temperature rise quickly

4,Low charges of installation and working

5,Easy maintenance

6,Automated management

7,No pollution

8,Heating cable is suitable for complex pipeline

9,Heating cable is suitable for long pipeline

10,Heating cable is suitable for instrument box
