Underfloor Heating System 3m Heat Tracing Cable With Pvc Pipe
- SHENZHEN
- T/T Money Gram
You May Like
-
High Quality Ceiling 15w Electric Heating Cable
-
RXRL 1400 Cross Section of High Quality Heating Cable
-
RXRL980 Best Prices Silicone Rubber Floor Heating Cable
-
2012 High Quality Water Proof Floor Heating Cable
-
Pipe Freeze Water Proof Silicone Heating Cable
-
220V High Quality Silicon Best Price Heating Cable
Product Details
| Place of Origin | Guangdong, China | Brand Name | szrunxiang | |
| Model Number | RX-Self-regulating heating cable | Conductor Material | Other, Alloy resistance wire | |
| Insulation Material | Rubber | Jacket | PVC | |
| Number of Conductors | 8 | Application | pipe/underfloor |
Product Description
Specifications
1,Energy saving2.Automated management
3.No pollution
4.Top quality and fast delivery
5.OEM is ok
underfloor heating system 3m heat tracing cable with pvc pipe
The cross section of heat tracing cable
The advantage of heat tracing cable
1.Electric heat tracing temperature uniform,no overheating,safe and reliable
2.Energy saving
3.Intermittent operating.temperature rise quickly
4.Low charges of installation and working
5.Easy maintaining
6.Automated management
7.No pollution
8.Heating cable is suitable for complex pipeline
9.Heating cble is suitable for long pipeline
10.Heating cable is suitable for instrument box
The describletion of heat tracing cable
| SINGLE HEATING CABLE SPECIFICATION MODEL(220V 18W/M) | ||||||||||||
| Product Type | Rated power (W/ROOT) | Rated voltage (V) | Linear power (W/M) | Standard length (M/ROOT) | Nominal resistance (Ω/ROOT) | |||||||
| RXRL/1R300/18 | 300 | 200 | 18 | 16.67 | 161.33 | |||||||
| RXRL/1R500/18 | 500 | 200 | 18 | 27.78 | 96.8 | |||||||
| RXRL/1R550/18 | 550 | 200 | 18 | 30.56 | 88 | |||||||
| RXRL/1R700/18 | 700 | 200 | 18 | 38.89 | 69.14 | |||||||
| RXRL/1R800/18 | 800 | 200 | 18 | 44.44 | 60.5 | |||||||
| RXRL/1R1000/18 | 1000 | 200 | 18 | 55.56 | 48.4 | |||||||
| RXRL/1R1100/18 | 1100 | 200 | 18 | 61.11 | 44 | |||||||
| RXRL/1R1200/18 | 1200 | 200 | 18 | 66.67 | 40.33 | |||||||
| RXRL/1R1300/18 | 1300 | 200 | 18 | 72.22 | 37.27 | |||||||
| RXRL/1R1400/18 | 1400 | 200 | 18 | 77.78 | 34.57 | |||||||
| RXRL/1R1500/18 | 1500 | 200 | 18 | 83.33 | 32.27 | |||||||
| RXRL/1R1800/18 | 1800 | 200 | 18 | 100 | 26.89 | |||||||
| RXRL/1R2100/18 | 2100 | 200 | 18 | 116.67 | 23.05 | |||||||
| RXRL/1R2300/18 | 2300 | 200 | 18 | 127.78 | 21.04 | |||||||
| RXRL/1R2500/18 | 2500 | 200 | 18 | 138.89 | 19.36 | |||||||
| RXRL/1R2800/18 | 2800 | 200 | 18 | 155.56 | 17.29 | |||||||
| RXRL/1R3000/18 | 3000 | 200 | 18 | 166.67 | 16013 | |||||||
| RXRL/1R150/18 | 150 | 200 | 30 | 5 | 322.67 | |||||||
Technical parameters
1,temperature range: Max maintenance temperature 65°C.
Max surface temperature 70°C±5°C.
Max bearing temperature 105°C.
2,Installation temperature:Min -60°C.
3,Thermo stability:Recycle 300 time from the temperature 10°C to 99°C,the heating value can keep 90% at least.
4,Bend radius:room temperature 20°C,the value is 25.4mm.room temperature −30°C,the value is 35.0mm.
5,Insulation resistance:when the length of heating cable is 100m,ambient temperature is 75°C,tested by 2500V DC tramegger 1 minute,the value of insulation resistance is 1200MΩ.
Heat tracing cable specification
Product Type | Rated power | Standard length | Nominal resistance | Resistance per meter |
RXRL/1R300/18 | 300 | 16.67 | 161.33 | 9.86 |
RXRL/1R500/18 | 500 | 27.78 | 96.8 | 3.485 |
RXRL/1R550/18 | 550 | 30.56 | 88 | 2.88 |
RXRL/1R700/18 | 700 | 38.89 | 69.14 | 1.778 |
RXRL/1R800/18 | 800 | 44.44 | 60.5 | 1.361 |
RXRL/1R1000/18 | 1000 | 55.56 | 48.4 | 0.871 |
RXRL/1R1100/18 | 1100 | 61.11 | 44 | 0.72 |
RXRL/1R1200/18 | 1200 | 66.67 | 40.33 | 0.605 |
RXRL/1R1300/18 | 1300 | 72.22 | 37.27 | 0.516 |
Product Show
1.We are professional manufacture of optical fiber cables in China.
2.OEM is accepted.
3.The cable size and material are customized,and your own logo or design are welcome.
4.We'll reply you in 12 hours after you send enquiry to us.
Certification
Factory
