12500lbs 12v DC 4x4 Electric Winch

FOB Price

US$ 180 - 200 / Unit

5 Units(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Jinglei
Model Number	JL-12500		Warranty	3 Years

12500LBS electric winch:

1. 12v or 24V DC ;

2. Water proof ;

3. Low noise(silence with patent; Patent No: 201410553072.9 ) ;

4. continuous working time: above 2 hours;

5. Double-way brake model(with 2 choices for installation on auto);

6. 3 years warranty & long life time.

Product Description:

JL-12500 LBS

Specification

Single line rated pull	12500lbs (5681kgs)
Motor	6.0hp/4.5kw, series wound
Control	Remote switch
Extra wireless remote switch	Optional
Gear train	3 stage planetary
Gear reduction ratio	194:1
Braking	Automatic load-holding brake
Drum size	Diameter 2.5’’ (63.5mm) x length 9.6’’(224mm)
Cable	3/8’’ (9.5mm) x 85’(26m)
Remote control switch	Included
Battery	Recommended:650 CCA
Net weight	40.5kgs
Overall dimension(Length x width x height )	20.8’’ x 6.3’’x 8.6’’ (530x160x218mm)
Mounting bolt pattern	10’’ x 4.5’’ (254x114.3mm)

Pull , speed , amps

Line pull and rope capacity in layer
