X6336 Supermax Milling Machine Parts
universial milling machine
1. Main Feature
· CE ISO Certificate.
· Manufactures. Easy Operation.
· Rectangular Table Guideways with High Stability
· Hardened and Ground Table Surface
· Automatic Feeds on X,Y Axis, Motorized Lifting and Falling of Table on Z Axis
· Headstock Swivels ±45°
·Taiwan High Speed Milling Head
· Vertical Milling Spindle Auto-Feeding
universial milling machine
2. Specification
| Specifications | X6336 Milling Machine |
| Spindle Taper | ISO 40 (Vertical) ISO 50 (Horizontal) |
| Distance From Vertical Spindle To Worktable(mm) | 135~485 |
| Distance From Horizontal Spindle To Workable(mm) | 0~350 |
| Distance From Horizontal Spindle To Arm(mm) | 230 |
| Spindle Speeds(R.P.M) | 78~6980(Vertical)60~1800 (Horizontal) |
| Table Size(mm) | 1250×360 |
| Max. Travel of Table(mm) | 1000×315×350 |
| Main Motor Power(Kw) | 5.5(Vertical) 4(Horizontal) |
| Arm Travel(mm) | 500 |
| Overall Dimension(mm) | 2220×1790×2360 |
| N.W./G.W.(Kg) | 2500/2700 |
universial milling machine
3. Sample Picture
universial milling machine
4. Accessories
universial milling machine
5. Optional Cutters
Wooden Cases/ Pallets
universial milling machine
Other Hot Sale Model Choices
Click Here Click Here Click Here Click Here
universial milling machine
Our Workshop
universial milling machine
Our Clients
