High quality 100 watt polycrystalline solar panel for home solar panel kits paneles solares with CE Tuv

FOB Price

USD $0.4 - $0.5 / Watt

1 Watt(Min.Order)

Supply Ability 1000000 Watt / Watts per Month
Port Shanghai
Payment Terms:T/T D/P D/A Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Shanghai, China	Brand Name:	Just Solar	Model Number:	JST100P(36)
Type:	Other, Solar Panel 100 watt

Product Description

Dimensions

IV-Curves

Note!

Please contact support for technical support. The actual transactions will be subject to the contracts. This parameters are for reference only and it is not a part of the contracts. The specifications are subject to change without prior notice.

Technical Data

Model Type	JST20M(36)	JST30M(36)	JST40M(36)	JST50M(36)
Peak Power	20W	30W	40W	50W
Module Efficiency	10.20%	12.20%	11.60%	14.60%
Maxi Power Voltage	18V	18V	18V	18V
Maxi Power Current	1.12A	1.67A	2.23A	2.78A
Open Circuit Voltage	22.5V	22.5V	22.5V	22.5V
Short Circuit Current	1.17A	1.75A	2.34A	2.92A
Power Tolerance	0 to+5W
	Mechanical Data
Cell Type	Monocrystalline 125x125mm
Number of Cells	36
Glass	High Transmission,Low Iron,Tempered Glass
Frame	Anodized Aluminium Alloy
Junction Box	IP67rated MC4 compatible
Dimension	64030625mm	45054525mm	63054535mm	63054535mm
Weight	2.1kg	2.3kg	3.3kg	3.3kg

Payment Terms

Payment Terms	T/T	FOB	30% T/T in advance, paid the balance before shipment
		EXW
		CIF	30% T/T in advance, paid the balance against copy of B/L
		CFR(C&F)
	L/C	L/C amount above 50,000 usd, we can accept L/C at sight
	Western Union	Amount lower than 53000usd
Delivery Time	10~15 days after receiving payment for one container

Packing

Packing Information
Container	20GP	40GP	40HP
Pieces per Pallet	26	26	26
Pieces per Container	356	728	812

Shipping

By Sea	Delivery from Shanghai, Yiwu and Ningbo seaport
By Air	Departure from Shanghai Pudong Airport
By Express	Post by DHL, EMS, UPS, TNT.

Contact Us

Shanghai Just Solar Co., Limited: Contact nameFrank Yang; Phone0086-21-53550075; Address518B, 1357 Huqingping Road
