High Voltage capacitor module 20kv 151K stacked capacitor
INTRODUCTION
Characteristics:
1)Operating temperature range-25°C~+85°C,
2)Small size, high withstand voltage,
3) Excellent performance of charging and discharging,
4)Large insulation resistance ≥104MΩ
Applications:
Used for high voltage power source, such as printer, electrostatic paint spraying equipment, color TV sets focus and voltage-multiplying circuit.
MODELS OF SERIED DISCS CAPACITOR
TYPE |
NONIMAL CAPACITANCE AND TOLERANCE |
RATED VOLTAGE (KVDC) |
NO. Of DISCS IN SERIES |
OUTLINE SIZE (mm) |
|
CAP. (pF) |
TOL |
||||
CT813-20KV-331PF |
331 |
+/-5%,+/-10% |
20 |
8 |
6*36 |
CT813-20KV-350PF |
350 |
+/-5%,+/-10% |
20 |
12 |
6*60 |
CT813-20KV-471PF |
471 |
+/-5%,+/-10% |
20 |
8 |
11*35 |
Dongguan Amazing Electronic Co.,Ltd. is specializing in manufacturing various kinds of high voltage and high frequency ceramic capacitors.Welcome to contact us for further information.
