Help CenterHigh Voltage Capacitor Module 20KV 330pf High Voltage Capacitors With Diodes
Related Products
-
China Manufacturer 10KV 103 10000pf High Voltage Ceramic CapacitorUS$ 0.55 - 3.21MOQ: 100 Pieces -
China Manufacturer 15KV 102 1000pf High Voltage Ceramic CapacitorUS$ 0.07 - 0.11MOQ: 10 Pieces
-
China Manufacturer High Voltage Class 1 Ceramic Capacitor 100kV 700pF, Screw Terminal Mounting, DoorknobUS$ 12.50 - 25.95MOQ: 1 Piece
-
China Manufacturer 15KV 103 10000pf High Voltage Ceramic CapacitorUS$ 0.30 - 0.40MOQ: 10 Pieces
-
High Voltage Class 1 Ceramic Capacitor 20kV 500pF, Doorknob, Screw Terminal MountingUS$ 10.35 - 22.07MOQ: 10 Pieces
Specifications
1.high voltage stack capacitors 20kv 330pF
2.small size, high withstand voltage
3.insulation resistance
4.with diodes
Sprayer 20KV 330pf ceramic stack capacitors
The main features of this stack Capacitor:
1. 20KV 500PF high voltage stacks ceramic capacitor in stock with SGS certificates
2. Small size, high withstand voltage
3. Insulation resistance>/=10000ohm
4. Operating Temp.Range:-25°C~+85°C, Excellent performance of,charge and discharge, Insulation Resistance ≥104MΩ
The detailed description of this stack Capacitor:
1. Recommended Applications:
1. High voltage power supply circuit in duplicator.
2. Electrostatic spraying equipment, etc.
3. Color TV sets focusing and voltage-multiplying circuit.
2. Characteristics:
1). Operating temperature range-25°C~+85°C.
2). Small size, high withstand voltage.
3). Excellent performance of charging and discharging.
4). Large insulation resistance ≥10000MΩ
3. Models of series stack discs Capacitor:
|
Model No
|
NONIMAL CAPACITANCE AND TOLERANCE |
RATED VOLTAGE (KVDC) |
NO. Of DISCS (PCS) |
OUTLINE SIZE D*L (mm) |
|
CAP. (pF) |
TOL |
D, L, t | |||
MZS12N20KV501K |
500 |
+/-10% |
20 |
12 |
6.5, 65.0, 3.5 |
MZS12N20KV471K |
470 |
+/-10% |
20 |
12 |
8.6, 78.0, 3.5 |
MZS12N20KV361K |
360 |
+/-10% |
20 |
12 |
8.0, 60.0, 3.5 |
MZS12N20KV331K |
330 |
+/-10% |
20 |
12 |
6.0, 58.0, 3.5 |
| MZS12N20KV301K | 300 |
+/-10% | 20 | 12 | 5.0, 65.0, 3.5 |
| MZS10N10KV251K | 250 | +/-10% | 10 | 10 | 6.5, 56.0, 3.5 |
| MZS12N20KV151K | 150 | +/-10% | 20 | 12 | 6.0, 60.0, 3.5 |
| MZS12N25KV221K | 220 | +/-10% | 25 | 12 | 5.6, 72.0, 3.5 |
4. Followings are pictures of our main products:
