Embedded Serial Device Server Module

FOB Price

USD $1 - $50 / Piece

1 Piece(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	3onedata
Model Number	NPM301

Product Description

Embedded Serial Device Server Module

Introduction

NPM301 is high-performance industrial embedded module that allows users to convert serial port to Ethernet port, which can satisfy various common requirements of users for power consumption, temperature, size and processing ability under complex environment. The compact size makes it possible to be embedded in all industrial control equipment, and provide non-blocking serial communication. The rich GPIO resources give you more flexible space for developing functions that satisfy customer’s diversified requirements.

Features

1. Support 32-bit ARM processor
2. Adopt 10/100M self-adaptive Ethernet interface
3. Support AUTO MDI/MDIX, crossover cable or straight-through cable connection optional
4. Support 300bps-115200bps non-blocking communication
5. Support low power consumption mode and high performance mode
6. Support TCP, UDP, ARP, ICMP, DHCP and DNS protocols
7. Support TCP Server, TCP Client, TCP Auto, UDP and Real COM driver working modes
8. Support cross-gateway and cross-router communication
9. Support standard TCP/IP SOCKET application access
10. Support virtual serial port driver access mode and automatic recovery of network
11. Provide Windows configuration tools that are easy-to-use and can be used in mass installation
12. Support AT command and WEB configuration modes
13. Low consumption design
14. Working temperature -40~75℃

Specification
System	32-bit ARM processor
Ethernet port	Standard: 10Base-T/100Base-TX Protocol: TCP, UDP, ARP, ICMP, DHCP and DNS Rate: 10/100M Working mode: full or half duplex Work pattern: TCP Server, TCP Client, TCP Auto, UDP and Real COM driver under low power consumption and high performance modes
Serial Port	Interface: support TXD, RXD, RTS, CTS, DTR, and DSR signals, and 4 sessions Parity bit: None, Even, Odd, Space, Mark Data bit: 5bit, 6bit, 7bit, 8bit Stop bit: 1bit, 2bit Baud rate: 300bps~115200bps Flow control: support RTS/CTS flow control or no flow control
Software	Configuration: WEB browser, Windows HyperTerminal, BlueEyes_II management software, virtual serial port driver
Power Supply	Power input: 3.3VDC Low power mode No-load power: 0.2442W@ 3.3VDC Full-load power: 0.2409W@ 3.3VDC High performance mode No-load power: 0.4092W@ 3.3VDC Full-load power: 0.4092W@ 3.3VDC
Environment Requirement	Working temperature: -40~75℃ Storage temperature: -40~85℃ Relative Humidity: 5%~95 %( no condensation)
Physical Characterisitics	Size (HWD): 32.5mm×25.0mm×8.5mm(Including pin) upper 14 pins, lower 14 pins Weight: 50g
Warranty	5 years

Dimension

Order Information

NPM301: 1-way Embedded Serial Device Server Module , 3.3VDC
