RT5572 802.11a/b/g/n 300Mbps 2.4G+5G dual band wireless wifi usb adapter
| Packaging Details: | Unit weight: 50g 100pcs/carton N.W: 6kgs G.W: 7kgs Meas: 37*31*31 cm |
| Delivery Detail: | 5-7 days |
| Packaging Details: | Driver CD *1pc USB WiFi Adapter * 1pc User manual * 1 |
Specifications
1. 802.11a/b/g/n dual band
2. 300Mbps peak rate.
3. Ralink RT5572 chipset
4. With WPS function
5.2T2R MIMO Mode.
1. 2T2R MIMO 300Mbps 802.11 a/b/g/n high speed USB WIFI Adapter support Soft-Ap functin
2.MINI Size Wi-Fi USB Dongle With WPS botton
3.Support OS: Android, Linux, Mac, Windows7 /8 etc
4.Application for IP TV, IP Camera, Set top box, Dream Box, Multimedia player, Sound box, Laptop, desktop, etc
5.Two years quality warranty
Main Chipset |
Ralink RT5572N |
|
Host interface |
USB 2.0 Type A |
|
LEDs |
one indicates WiFi link&activity,Wpsstatus indicator
|
|
Antennas |
2 built-in onboard 2.4/5 GHz PCB antennas. |
|
Operation Frequency |
ISM band , 2412~2483.5MHz , 4915~5825MHz (Detail frequency range depends on country region). |
|
|
Typical Transmit Power (before antenna) |
802.11a (OFDM) 54Mbps: 10+/-1dBm |
|
802.11b (CCK) 11Mbps: 18+/-1dBm | ||
802.11g (OFDM) 54Mbps: 15+/-1dBm @ EVM <-31dB | ||
802.11n (HT20@MCS7), 15+/-1dBm,(HT40@MCS15),14+/-1dBm | ||
|
Receive Sensitivity (after antenna) |
802.11a: -66+/-1dBm |
|
802.11b: -88+/-1dBm | ||
802.11g: -73+/-1dBm | ||
802.11n (HT20), -70+/-1dBm;802.11n (HT40), -72+/-1dBm | ||
Operation System |
Windows XP 32/64, Windows 2000, Vista 32/64, Windows7 32/64, Windows8 32/64, Linux 2.6.X, Mac OS X |
|
Security |
WEP 64/128, WPA/WPA2 (TKIP,AES); WAPI; WPS/WPS2.0; PIN; PBC |
|
Voltage Range/Current |
DC 5.0V ± 5% / <330mA @802.11g;3.3VDV± 5% <350mA, @802.11n,HT40
|
|
Physical Specification | ||
Dimensions |
67.75*22.8*8.5mm |
|
1. 12 months warranty
2. OEM & ODM is available.
3. High quality with best service
4. each cables will be tested over 3 times before shipment
Contact person: Zola | skype:live:szxinhuatian | QQ:2398402087
Q: What's your MOQ?
A: No MOQ, Mixed order welcome.
Q: What's the Payment Term?
A: We accept T/T, Cash, Money Gram, Western Union.
30% deposit, 70% T/T Before shipment.
Q: Can we get samples?
A: Yes, we can provide the regular samples.
Q:Do you accept the OEM or ODM order?
A: Yes, we accept OEM and ODM order, Customized design is available.
Q: What's your quality assurance?
A: Quality warranty is 1 year.
