Mini 2T2R 2dBi Built in Wlan PCI-E Card Wireless 300Mbps RT5392 WiFi USB Dongle with External Antenna
Pakaging Details: Unit weight: 65g 100pcs/carton N.W: 9 kgs G.W: 10 kgs Meas:59*38*32 cm
Delivery Detail: 3-5 days
Packaging Details: Driver CD * 1 pc USB WIFI Adapter * 1pc 2dbi Antenna * 2 pc
This 300Mbps 2T2R PCI-E Adapter is fully compliant with IEEE 802.11n 2.0 specification;
it allows users to connect to 802.11n wireless networks up to 300 Mbps.
It is also backward-compatible with IEEE 802.11b/g wireless network at 11/54 Mbps respectively.
This PCI-E adapter includes a convenient utility software for scanning available wireless networks and an option to save profiles of preferred networks at user’s choice.
Configurable wireless security and encryption software are also included.
Features
• Two 2dBi or 5dBi dipole antennas with R-SMA connectors
• Driver available in Windows® XP, Windows Vista® and Windows® 7/8
• Simple user setup & diagnostics utilities
Specifications
Standard:
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n 2.0
Radio Technology:
IEEE 802.11g / IEEE 802.11n: Orthogonal Frequency Division Multiplexing (OFDM)
IEEE 802.11b: Direct Sequence Spread Spectrum (DSSS)
Interface:
PCI Express Rev. 1.1
Security:
64/128-bits WEP Encryption
WPA-PSK, WPA2-PSK, WPA, WPA2
Wireless LAN Frequency Range:
2412 ~ 2484 MHz ISM band (channels 1 ~ 14)
Range Coverage:
Indoor: Up to 100 meters (depends on environment)
Outdoor: Up to 300 meters (depends on environment)
Transmission Rate:
1, 2, 5.5, 6, 11, 12, 18, 22, 24, 30, 36, 48, 54, 60, 90, 120, 180, 240, 270, 300Mbps (auto sense) for Rx and Tx
Receiver Sensitivity:
300Mbps: Typical - 65dBm @ 10% PER
54Mbps: Typical - 68dBm @ 10% PER
11Mbps: Typical - 84dBm @ 8% PER
Modulation Schemes:
DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM)
Media Access Protocol
CSMA/CA with ACK
Transmit Power:
< 18dBm typically @ 802.11b
< 15dBm typically @ 802.11g
< 13dBm typically @ 802.11n
Antenna:
Two 2dBi or 5dBi dipole antenna with R-SMA connector
Diagnostic LED:
Activity Status
Operating Temperature:
0 ~ 40°C
Storage Temperature:
-10 ~ 70°C
Humidity:
10% ~ 95% RH, no condensation
Certifications:
FCC Part 15.247 for US
ETS 300 328 for Europe
Channel:
USA: 11
Europe: 13
Japan: 14
Driver Support:
Windows® 7/8/ XP; Windows Vista®
Package Content
• Wireless PCI-E Adapter x1
• External and Detachable Antenna x2
• Installation CD x1 (User Manual on CD-ROM)
Requirement
• Operating System: Windows® 7/8 / XP; Windows Vista®
• Available 1x PCI-E slot
• CD-ROM Drive
1. 12 months warranty
2. OEM & ODM is available.
3. High quality with best service
4. each cables will be tested over 3 times before shipment
Contact person: Carmen |skype:live:szxinhuatian |WeChat:0086-13798299708
Q: What's the Payment Term?
A: We accept T/T, Cash, Money Gram, Western Union.
30% deposit, 70% T/T Before shipment.
Q: Can we get samples?
A: Yes, we can provide the regular samples.
Q:Do you accept the OEM or ODM order?
A: Yes, we accept OEM and ODM order, Customized design is available.
Q: What's your quality assurance?
A: Quality warranty is 1 year.
