6Kg ozone generator for industrial waste water treatment

We are OBM and ODM manufactory, We also accept OEM.

We own our core technology, large sales teams, strong R&D team and standardized production workshop.

Have strong competitive advantages on quality and price.

Our R & D team always leads ozone technical reform and innovation.

Our markets extend to all over the world.

Allied Power ozone generator technology advantages:

1. Adopt high frequency power supply system which made by us strict quality control. It is smaller, low electric consumption and high efficiency than other medium frequency or low frequency power supply system.

2. We introduce international micro-gap discharge technology, quartz glass tubes honeycomb discharge. Quartz glass tubes produce ozone with high efficiency than enamel tubes. High dielectric constant is not easy be punctured by high voltage. So quartz glass tubes working life is longer than enamel tubes or plates.

3. Compare to air cooling system, our water cooling system with good cooling effect. It could improve ozone output and concentration.

4. Pure oxygen as gas feed, our highest ozone concentration could reach 230mg/h.

5. When ozone concentration is 100mg/h, electric consumption is 7Kw/(kg*h)

6. Wecon PLC micro computer control, touch screen human-machine display.

7. Adopt stainless steel 304 ozone reaction cavity and stainless steel 316 discharging tubes.

8. We are specialized on ozone generator and high frequency inverter R&D, production for many years. So our ozone generator could well match to our high frequency power supply system. So our ozone generator working stable and high efficiency, low decay, low electric consumption than most ozone generators suppliers.

Our ozone high frequency inverters get many international patents. Less ozone generator suppliers could produce ozone generator at the same time produce soft-switch power supply system like us

Item No.

Ozone Output (g/h)

Concentration(mg/L)

Rated power(kw)

Air

flow rate

(m³/h)

Cooling water

flow

rate

(m³/h)

Working pressure(Mpa)

Air dew point(°C)

Relative humidity

Power supply (V/Hz)

Power consumption (kwh/kgO₃)

Weight (Kg)

Installation environment

HW-A-1K

1K

35

17

29

4

0-0.2

-45

≤60%

380V/

3PH

/50H Z

17

800

Indoor

Remark:

1. The final price will be subject to the approval sample and order quantity.

2. Terms of payment: T/T 30% payment as deposit and the balance 70%T/T payment against the copy of B/L.

3. Delivery time: 30 days after everything confirmed and receive 30% deposit.
