Copper Pipe Tube Straightening Machine

Copper Pipe Tube Straightening Machine thumbnail-1
Copper Pipe Tube Straightening Machine photo-1
US$ 16000.00 - 40000.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
JSY
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiasye Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name JSY
Model Number BLXZBT-8
Voltage 380V
Rated Power 5.5kw
Dimension(L*W*H) 2800*1000*1350mm
Weight 850KG
Certification SGS
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Copper pipe straightening machine

China copper pipe tubing cutting and straightening machinecopper tube straighener and cutting machine miany for aluminum tube decoiling, straightening andcutting.it can be design as single coil tube processing, 2 line, 4 line, 6 lines series. The speed will be little difference against the diameter and material hardness.More requiremenet, pls contact us free.

Main Parameter
No.
Item
Detail
Memo
1
tube diameter range
OD 4.0—8.0mm
bigger size for 8-18mm
2
tube thickness range
0.50-1.0mm
/
3
tube straightening length range
100-50000mm
/
4
straightening working speed
>=45meter/minute
different as tube size
5
Material collection shelf
prepared by the user
/
6
length cutting tolerance
+/-1mm
/
7
power supply
380V/50Hz
3 phases 4 wires type
8
motor power
5.5KW, rev1440/rpm
Material feeding motor
2.2KW, rev1440/rpm
cutting motor
9
the pressure the air compressor
3MPa
Just need 0.6-0.8MPa in working
10
dimension
4000X1000X1350mm
Not included the material collection shelf
11
weight
2000KG
/
Products Show
