YT-L900 Ruian Paper Cup Cutting/Paper Die Cutting/Paper Punching/Creasing Machine

YT-L900 Ruian Paper Cup Cutting/Paper Die Cutting/Paper Punching/Creasing Machine photo-1
US$ 1 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Die-cutting Machine
Computerized:
Other, PLC
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Die-cutting Machine
Computerized Other, PLC
Place of Origin Zhejiang, China
Brand Name YT
Model Number YT-L900
Voltage 380V 50Hz
Power(W) 6.3kw
Dimension(L*W*H) 3000*1600*2000mm
Weight 2100kgs
Certification CE Certificate
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

YT-L900 Ruian Paper Cup Cutting



  YT-L900 Die Cutting Machine adopts the technology cutting of automatic punching. It can make the slitting, die cutting and clearing the waste of paper done together. So the machine has less steps than those with the traditional cutting technology, which can eliminate some loss of the raw material in cutting, and can improve the rate of the utilization of raw materials and finished goods effectively. The machine removes the waste clearing step in traditional procedures and cuts the pattern paper directly which are in good quality and looks nice. So it is a good machine which can not only largely reduce the consumption and manpower of worker, but also reduce worker’s labor intensity. It is ideal equipment for cutting many kinds of paper container, such as disposable paper bowl, paper cup, paper meal, paper box, lable paper, etc. it adopts professional high definition gas feeding paper structure, distinctive electronic protector and automatic feeding paper and collecting paper orderly. It is controlled by PLC, which makes the whole working procedure are automatic. And through the PLC control, the worker can get the whole data if the working machine, such as the speed, the power of motor, the amount of the pattern paper and so on. If u want to produce different pattern paper, what the worker can do is that changing the parameters on the interface of PLC, what is more, the important parts of machine are imported from Japan and Germany. From the above, this machine can run stably, locate correctly and operate safely, reliably and easily.

YT-L900 Ruian Paper Cup Cutting/Paper Die Cutting/Paper Punching/Creasing Machine

Technology Specification:

Cutting speed

150-250times/min

Required paper

150-350g/sm, width:355-880mm

Weight

2100kg

Paper Max width

900mm

Way of cutting

Roll paper

Mould board size

900*420mm

Total power

380v 50hz 6.3kw

Speed of sending paper

>40m/min(interval working)

Main roller length

1000mm

Size (L*W*H)

3000*1600*2000mm

Control system

PLC control

  Certification:

YT-L900 Ruian Paper Cup Cutting/Paper Die Cutting/Paper Punching/Creasing MachineYT-L900 Ruian Paper Cup Cutting/Paper Die Cutting/Paper Punching/Creasing Machine

Packaging & Shipping:
YT-L900 Ruian Paper Cup Cutting/Paper Die Cutting/Paper Punching/Creasing Machine

FAQ:



1.whats your product range?



Tea cups,coffee cups,ice cream cups,noodle bowl, KFC bowl ,paper bag,etc.







2..Are you a manufacturer?



 Yes,We have been in making paper cup machine for nearly 9 years since from 2006 And we have our own workshop.







3..What information should i let you know if i want to get a quotation?



 --Quantity



 --Whats the detailed size (top diameter,bottom diameter,and height)



 --Whats the paper sickness



 --It is usage







4.What about the delivery time?



 Usually 25 working days,but will depend on your quantity and size.







5.what about the payment term ?



Mostly 30%T/T  in advanced,the rest need paid before shipping.







6..whats your advantages ?



--8 years experience:We have been in making paper cup machine for 8 years.



--Customers all over the world



--Certificate: CE certificate,SGS certification.



--Patent: We have got patent of some products such as square paper cup mcahine.



--Fast reply:Our team will reply you soon.



--After-sale service:We have a after sale department , service for your problems and dealing with spare parts.
