DFD WATER SOLENOID VALVE 2 WAY G1/2''~G2''
US$ 17.5 - 748.3
MOQ: 1 Piece
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Diaphragm
Pressure:
Low Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DFD WATER SOLENOID VALVE SS G1/2''~G2''US$ 22.98 - 403.2MOQ: 1 Piece -
DFD GAS Liquid 2 WAY SOLENOID VALVE CAST IRON FLANGE DN40~2OOMMUS$ 37.28 - 432MOQ: 1 Piece
-
DFD Stainless Series Solenoid ValveNegotiableMOQ: 1 Piece
-
DFD-CF Flange Cast Iron Solenoid ValveNegotiableMOQ: 1 Piece
-
DFD-25JK WATER SOLENOID VALVENegotiableMOQ: 1 Piece
Standard or Nonstandard
Standard
Structure
Diaphragm
Pressure
Low Pressure
Power
Solenoid
Material
Brass
Temperature of Media
Medium Temperature
Media
Oil
Port Size
G1/2''~G2''
Place of Origin
Zhejiang, China
Brand Name
round star
Specifications
Many kinds of solid horizontal pressure diaphragm, has a reliable performance!Specifications
electric solenoid water valve
1) water application
2)max 12bar,IP65
electric solenoid water valve-
2W brass normally closed IP65 air oil water solenoid valve
Pilot Operated
Normal Pressure – 3/8″-2″
Valves available in normally closed and normally open constructions.
Available in either AC or DC operated with brass or Stainless Steel bodies.
Specifications:
- Media: Water, Air, Oil (below 20cst)
--Temperature: -5 ~80
--Mode of action: Pilot operated
-- Pressure: Normally Closed 12bar; Normally Open 8bar
--Function type: Normally Closed (N/C), Normally Open(N/O)
--Body material: Brass/stainless steel
-- Sealing material: NBR/FKM/EPDM
--Protection class: IP65
| MODEL | DFD-10 | DFD-15 | DFD-20 | DFD-25 | DFD-32F | DFD-40F | DFD-50F |
| MOTION TYPE | PILOT OPERATED | ||||||
| G CONNECTION | 3/8" | 1/2" | 3/4" | 1" | 1-1/4" OR FLANGE | 1-1/2" OR FLANGE | 2" OR FLANGE |
| NOMINAL DIAMETER MM | 15 | 15 | 20 | 25 | 32 | 40 | 50 |
| CV VALUE | 3.8 | 3.8 | 7 | 11.1 | 14 | 24.5 | 35 |
| PRESSURE BAR | NORMALLY CLOSED 0.3-12 ( 0.3-10); NORMALLY OPEN: 0.3-8 | ||||||
| MEDIUM TEMP | NBR -5-80 SPECIAL VITON (-10-130) | ||||||
| POWER | 220V-230V AC /50-60HZ; 110V-120V AC/50-60HZ; DC 24V; DC 12V; RANGE;+/- 10% | ||||||
