DFD-25JK WATER SOLENOID VALVE
- 1000 Piece / Pieces per Month
- Ningbo/Shanghai China
- Credit Card
Product Details
Standard or Nonstandard: | Standard | Structure: | Diaphragm | Pressure: | Low Pressure |
Power: | Solenoid | Material: | Brass | Temperature of Media: | Medium Temperature |
Media: | Oil | Port Size: | G3/8''~G2'' | Place of Origin: | Zhejiang, China |
Brand Name: | round star |
Product Description
Specifications
Many kinds of solid horizontal pressure diaphragm, has a reliable performance!Specifications
electric solenoid water valve
1) water application
2)max 12bar,IP65
normally closed IP65 air oil water solenoid valve
Pilot Operated Normal Pressure – 3/8″-2″
Valves available in normally closed and normally open constructions.
Available in either AC or DC operated with brass or Stainless Steel bodies.
- Media: Water, Air, Oil (below 20cst)
--Temperature: -5 ~80
--Mode of action: Pilot operated
-- Pressure: Normally Closed 12bar; Normally Open 8bar
--Function type: Normally Closed (N/C), Normally Open(N/O)
--Body material: Stainless steel/ Brass
-- Sealing material: NBR/ FKM/ EPDM
--Protection class: IP65
MODEL | DFD-10J | DFD-15J | DFD-20J | DFD-25J | DFD-32JF | DFD-40JF | DFD-50JF |
MOTION TYPE | PILOT OPERATED | ||||||
G CONNECTION | 3/8" | 1/2" | 3/4" | 1" | 1-1/4" OR FLANGE | 1-1/2" OR FLANGE | 2" OR FLANGE |
NOMINAL DIAMETER MM | 15 | 15 | 20 | 25 | 32 | 40 | 50 |
CV VALUE | 2.2 | 3.73 | 7 | 11.1 | 14 | 24.5 | 35 |
PRESSURE BAR | NORMALLY CLOSED 0.3-12 ( 0.3-16); NORMALLY OPEN: 0.3-8 | ||||||
MEDIUM TEMP | NBR -5-80 SPECIAL VITON (-10-130) | ||||||
POWER | 220V-230V AC /50-60HZ; 110V-120V AC/50-60HZ; DC 24V; DC 12V; RANGE;+/- 10% |
