Specifications
Superior handling,Flexible scalability,High reliability and stability,Perfect protection,Small and light flexibility.
Shanghai Lingguang Electric Apparatus Manfacturing Co.,LTD (Lingo)established in 1991.
Professional industrial electrical products -- resistance box, load box, center grounding resistance, manufacturers in domestic resistor manufacturing enterprises have higher visibility.
With nearly 150 employees, scientific and technical force is abundant, has many national patents (Example: ZX18V type resistors, patent number 03230790).
Had including CNC plate shears, CNC folding machine, CNC punching, more than 60 sets of large-scale processing equipment.
Enterprise through IS09001 quality system, ISO14001.2004 environmental management system and GB/T2800-2001 worker health and safety management system.
LINGO widely used in steel, electric power, ship, railway, electronics, and etc, the products have been exported to Japan, France, Germany, Egypt, etc.
LINGO is located in Shanghai PuDong new area, has a total area of about 9,000 square meters workshops, warehouses and office center.
Excellent ability of research development
The advanced production processing equipment
Complete production assembly processing capacity
Perfect quality guarantee system
Quickly logistic support capacity
Timely and efficient service response
Enterprising management team
With first-class product quality to win the trust of customers
With first-class marketing quality to win the confidence of users
With first-class service quality to win the satisfaction of customers
The dry-type load the box with our own R & D stereotypes resistance tube, Each resistance tube, resistance and capacity of the error of ± 3%.The resistance tube has used the stainless steel pipe and the stainless steel radiator fin, in the tube are full of material (Mgo), has sealed the steel pipe two ends, Therefore the high quality may maintain for a long time. Using the forced air convection method to cool the resistance tube, and space saving, which can testing in a small space. The operator can easily operate the installment by our self research and develop software,We can set the parameters according to the testing requirements on computer,Easily view the contents of the tests and save and print a test report in testing, Once appear a cooling fan, resistance heap over-temperature fault. Immediately displayed on the computer failure and stop the load, Sound and light alarm device to prevent the electric cooling is not enough to damage the pipe.
Compared with the traditional: the weight is lighter, the testing us more accurate, current fluctuations are smaller, more secure, no leakage, do not produce harmful gases and waste water, protect costs, load regulation is more easily.
| NO | TYPE | LGFZ400-2400 |
| 1 | RATED POWER | 2400KW |
| 2 | RATED VOLTAGE | 400V |
| 3 | FREQUENCY | 50HZ |
| 4 | POWER FACTORY | 1.0 |
| 5 | Degree of protection | IP23(ELECTRIC IP54) |
| 6 | Insulation class | F |
| 7 | Work method | continues |
| 8 | dimension | 4000*2438*2591 |
| 9 | weight | about5T |
