Help CenterNeutral Earthing Resistor in Power Distribution Equipment
Related Products
Specifications
Neutral earthing resistor is applicable to 50(60)hz high voltage power transmission and distribution system.
Shanghai Lingguang Electric Apparatus Manfacturing Co.,LTD (Lingo)established in 1991.
Professional industrial electrical products -- resistance box, load box, center grounding resistance, manufacturers in domestic resistor manufacturing enterprises have higher visibility.
With nearly 150 employees, scientific and technical force is abundant, has many national patents (Example: ZX18V type resistors, patent number 03230790).
Had including CNC plate shears, CNC folding machine, CNC punching, more than 60 sets of large-scale processing equipment.
Enterprise through IS09001 quality system, ISO14001.2004 environmental management system and GB/T2800-2001 worker health and safety management system.
LINGO widely used in steel, electric power, ship, railway, electronics, and etc, the products have been exported to Japan, France, Germany, Egypt, etc.
LINGO is located in Shanghai PuDong new area, has a total area of about 9,000 square meters workshops, warehouses and office center.
Excellent ability of research development
The advanced production processing equipment
Complete production assembly processing capacity
Perfect quality guarantee system
Quickly logistic support capacity
Timely and efficient service response
Enterprising management team
With first-class product quality to win the trust of customers
With first-class marketing quality to win the confidence of users
With first-class service quality to win the satisfaction of customers
Neutral earthing resistor normal operational conditions:
The height above sea level of the installation site is less than 1500meters;
The ambient temperature can not exceed +40°c,the daily average temperture less than +32 °c and annual average temperature less than±25°c;
Install in explosive-free media,which are not corrosive metals or the gas and conductive dust likely to damage the insulation.,install at the moisture-free place,install at the places free from vibrations and strong bump .
Technical parameters:
| type | rated system voltage(kv) | rated voltage(kv) | short time permitted current(A) | short time power-on time | nominal resistanceΩ(±5%) |
| LMGR6.0-100-10 | 6.0 | 3.46 | 100 | 10 | 34.6 |
| LMGR6.0-200-10 | 6.0 | 3.46 | 200 | 10 | 17.3 |
| LMGR6.0-400-10 | 6.0 | 3.46 | 400 | 10 | 8.6 |
| LMGR6.0-600-10 | 6.0 | 3.46 | 600 | 10 | 5.7 |
| LMGR6.3-100-10 | 6.3 | 3.64 | 100 | 10 | 36.4 |
| LMGR6.3-200-10 | 6.3 | 3.64 | 200 | 10 | 18.2 |
| LMGR6.3-400-10 | 6.3 | 3.64 | 400 | 10 | 9.1 |
| LMGR6.3-600-10 | 6.3 | 3.64 | 600 | 10 | 6.0 |
ORDER TO KNOW:
As the resistor is usually used for the short time work system,and the power and the voltage level are subject to the power distribution system ,users must provide the following parameters when placing the order ,and the visual dimension shall be determined after the consultation between both parties.
1.rated power
2.rated resistance
3.rated current
4.rated voltage
5.power-on time
tection level
7.line incoming and outgoing modes
8.indoor or outdoor type
9.shell color
10.environmental conditions
11.whether with current transformer or other specific requirment
12.whether the preparation of epoxy cast dry-type transformer grounding
.
