XSG Series Revolving Flash Vaporization Dryer for Aluminum Calcium

Jiangsu Zhenxing Drying Equipment Co.,Ltd. is the most powerful in the drying equipment industry.It is the fixed-point production company of China National Chemical Equipment Corporation. Factory covers an area of 60,000 square meters,construction area of 24,000 square meters.We have more than 200 employees and more than 50 senior technician. With strong technical force and perfect production and more than 100 testing equipments, we produce various types of drying, mixing, granulating, dust, crushing equipment capacity of 6,000 sets. Production of varieties can be divided into more than 20 categories, nearly 100 varieties of specifications, we have unique advantages especially in the Mesh-belt drier, Oar dries,Vibrating-Fluidied Bed Rotating Drier, Air Steam Dryer,Vacuum dryer, Spray dryer,High-speed centrifugal spray dryer,Hot air circulating drying oven,Double cone rotating vacuum dryer,Rotary Drum Dryer, Boiling Dryer, Pharmaceutical Dryer, Starch Dryer, Chemical Dryers, Sewage Sludge Drying, Pharmaceutical Machine, Granulators Series, Mixer Series, Grinder Series, Sieving Series, Heat Source Series, Dust Series.

Since our company founded in 1992, it has been committed to research and develop drying equipment and relied on advanced technology and management experience, We conduct extensive technical exchanges and cooperation, and develop a batch of new and high technology products with domestic universities, research institutes actively.We also optimize and improve a group of professional equipment. After seven years of hard work, invested more than 15 million yuan of funds, established Changzhou's largest drying equipment testing center. Developed a sludge drying equipment, calcining device, dehydrated vegetables production line, pumpkin powder production line, medlar dehydration production line, yams drying production line, extracted alcohol production line.They are allwidely used in chemical, pharmaceutical, food, environmental protection, metallurgy, building materials, ceramics and other industries. Products are sold nationwide and exported to Europe, America, Southeast Asia, the Middle East.

 Absorbed the foreign advanced equipment and technology, our factory and
Shenyang Chemical Research Institute under the Chemical Ministry of the State has developed this machine. This is a new kind of drying equipment used for drying the materials, such as paste state, thixotropy, thermal sensitive powder and particles. Our factory id equipped with the test sample machine, which can be used for carrying out the drying tests of various feeds for our users and for to provide the parameters to select the applicable machine.

Principle:
The hot air enters into the bottom of the XSG Series Revolving Flash Vaporization Dryer for   Aluminum Calcium    in tangent direction. Under the driving of the stirrer, a powerful rotating wind field is formed. The paste state materials enter into the drier through the screw charger. Under the powerful function of the sitting vanes at high-speed rotation, the materials are distributed under the function of strike, friction and shearing force. The block state materials will soon be smashed and contact the hot air fully and the materials are heated and dried. The dried materials after the de-watering will go up with the heat-air flow. The step rings will stop and keep the big particles. Small particles will be discharged out of the drier from the of the equipment by centrifugal force function and be smashed again after they fall down to the bottom.

Features:
This machine combines the whirl technology with the fluidity ejection and smashing step technologies. The equipment is compact and small in size ,high in production efficiency and continuous in the production .It has realized that a small equipment can perform the large production.

The drying capacity for this machine is big but its energy consumption is low. Its hear efficiency can go up to more than 70%. The material star time is very short. The quality of the final products is very good. The machine can be used for drying the hest sensitive materials. For the negative pressure or the micro-negative pressure operation, the drying machine is good for its tightness and high in the efficiency so as to eliminate the environmental pollution.

 “Zhenxing”people in line with "the steadfast personhood, honest work" principle ,Sincerely look forward to cooperate with colleagues from all walks of life, create brilliance.
