4 Core Fire Alarm Cable
- Ningbo or Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Huajie or OEM | |
| Model Number | Alarm cable | Type | Coaxial | |
Product Description
Specifications
4core fire alarm cable:1.) Conductor: Bare copper or Tinned copper or Tinned CCA conductor
2.) Insulation: PVC,PE,HDPE
4 core fire alarm cable :
1> Conductor: Bare copper,Tinned copper ,Tinned CCA, CCA.
2> Insulation:PVC-flame proof
3> Cable core: 2, 4, 6, 8, 12,...20 are available
4> Shield: Al/polyester foil
5> Rip cord: synthetic fibers
6> Drain wire: CU/TC/TCCA/CCA
7> Jacked: PVC-flame proof. LSZH
Normal area (mm2) | Structure (mm) | Insulation dia. (mm) | Approx overall dia. (mm) | |
2x0.20 | 2x7/0.18 | 1.0 | 3.0 | |
4x0.20 | 4x7/0.18 | 1.0 | 3.5 | |
6x0.20 | 6x7/0.18 | 1.0 | 4.1 | |
8x0.20 | 8x7/0.18 | 1.0 | 4.5 | |
10x0.20 | 10x7/0.18 | 1.0 | 5.2 | |
2x0.22 | 2x7/0.20 | 1.12 | 3.0 | |
4x0.22 | 4x7/0.20 | 1.12 | 3.5 | |
6x0.22 | 6x7/0.20 | 1.12 | 4.1 | |
8x0.22 | 8x7/0.20 | 1.12 | 4.5 | |
10x0.22 | 10x7/0.20 | 1.12 | 5.2 | |
2x0.34 | 2x7/0.25 | 1.26 | 3.5 | |
4x0.34 | 4x7/0.25 | 1.26 | 4.2 | |
6x0.34 | 6x7/0.25 | 1.26 | 4.8 | |
8x0.34 | 8x7/0.25 | 1.26 | 5.5 | |
10x0.34 | 10x7/0.25 | 1.26 | 6.2 |
Workshop :
Braiding Machines:
PE/PVC Production Lines:
Manner Of Packing:
4 core fire alarm cable Packing Lengths:
100m/roll, 200m/roll, 305m/wooden drum , 500m/ wooden drum
Or according to client's request.
Text Equipment :
CE / ROHS Certificate :
If you are interested in this , please contact with us ,we will Quote the Best quality, the Best Competitive prices for you !
