50 ohm RG213 jumper cable
Specification Show
Electrical | |
Impedance |
50 Ω |
Frequency Range |
DC - 6 GHz |
Return Loss |
DC - 3 GHz > 32 dB; 3 - 6 GHz > 25 dB |
Dielectric Withstanding Voltage |
1,000 V rms, 50 Hz at sea level |
Working Voltage |
< 335 V rms, 50 Hz at sea level |
Insulator Resistance |
> 5,000 MΩ |
Center Contact Resistance |
< 3 mΩ |
Outer Contact Resistance |
< 2.5 mΩ |
RF Leakage |
DC - 3 GHz 80 dB minimum, 3 - 6 GHz 70 dB minimum |
Mechanical | |
Engagement Force |
5.6 lbs (25 N) |
Disengagement Force |
4.5 lbs (20 N) |
Retention Force for Interface |
> 13.5 lb (60 N) |
Mating Cycles |
100 |
Distance Between Connectors |
.49 inches (12.4mm) minimum |
Material | |
Body |
White bronze over brass |
Solder Body |
Gold over brass |
Pin Contact |
Gold over brass |
Socket Contact |
Gold over beryllium copper |
Outer Contact |
White bronze over spring bronze |
Insulator |
PTFE |
Crimp Ferrule |
White bronze over copper |
Environmental | |
Temperature Range |
-40°C to +80°C |
Products Show
Our Services
Why us?
1. We are the professional coaxial cable manufacturer, so we have rich production experience on the cables;
2. OEM/ODM is available, your own brand can be printed in both cables and boxes;
3. We have special quality control department to ensure our good quality;
4. Cables are approved based on CE, ROHS, 3C, ISO9001 quality standard;
5. Short delivery time, we can finish a 20ft container within 15 days.
