Help CenterRotary 1/2/3 Color PVC Sole Injection Moulding Machine (Energy Saving)
Related Products
-
TPR 3 COLOR SPORT SHOE SOLE INJECTION MACHINEUS$ 1 - 1.1MOQ: 1 Set -
Rotary Double Color TPU/TR PVC Shoe Sole Making MachineUS$ 1 - 1.1MOQ: 1 Set
-
Tr/tpu/rubber Double Color Outsole Shoe Making MachineUS$ 1 - 1.1MOQ: 1 Set
-
High Quality Tr/tpu Double Color Outsole Shoe Injection MachineUS$ 1 - 1.1MOQ: 1 Set
-
2 Station Double Color Tpr Shoe Sole Manufacturing MachineUS$ 1 - 1.1MOQ: 1 Set
HONKING Machinery Equipment Co., Ltd. Is a premier manufacturer of shoes making machine and related equipments.
Our factory is located in Dongguan, China which is called as "World Factory" and "Shoes Capital of Asia". We focus on the innovation, research and make of shoe making machine, and also work hard to solve various kinds of injection technology. We have machine for all kinds of material which have different type and hardness, such as TPR, PVC, TPU, TR, EVA, PU, RUBBER and so on.
Our professional products are as followed:
1. PVC shoes air blowing machine (1/2 color)
2. PVC jelly shoes injection moulding machine (1/2/3 color)
3. Rain boots injection moulding machine(1/2 color)
4. Rotary TPR/PVC/TPU/TR outsole injection moulding machine (1/2/3 color)
5. Vertical TPR/PVC/TPU/TR injection moulding machine (1/2 color)
6. EVA shoes injection moulding machine (1/2 color)
7. RUBBER injection moulding machine
8. Silicone injection moulding machine
9. PU injection moulding machine
10. PVC upper injection moulding machine (1/2/3 color)
We have been working well exporting to Europe, Africa, Asia, South America, Middle East, Russia, Turkey and so on. We believe that our success depends on your satisfaction with our products. We always adhere to the principle of "Quality First, Customer Supreme" and providing our best sales services for our customers. Our team of experienced engineers strives to continuously improve our technologies-----from hardware design to machine components making them the most durable and reliable in the marketplace. Our shoes machines are thoroughly tested, both in the design and throughout the entire production process.
FEATURES:
1. This machine is used to produce various kinds of one color outsoles for sport shoes, leisure shoes, slippers, sandals, man's and lady's shoes in general, etc.
2.It can used to inject first model for 1/2/3 color EVA material.
3.It is suitable for all kinds of thermoplastic raw materials, foaming or non-foaming, such as PVC and TPR.
4.Machine operation is controlled by full automatic computer and PLC. Saving labour and improving productivity.
5.The oil and electric circuit is controlled dependently. To reduce the waiting time, producing faster.
6.The injection volume of each station can be setted independently. It can use different moulds at the same machine, It saves time of mould-changing and extends the cooling time.
7.It uses small motor and new technology, saves half electricity than traditional machine.
8.With strong close mold base and lock mold power,which makes perfect quality.
9.Closing mold with two steps control which make no damage to the mold,
materials are injected by two steps pressures.
10.The machine's output is about 180pair/hour.
11.Servo system and auto-opener is selectable to save electricity and labour. (These two items canbe selected by customer).
Specification
| Technical terms | UNIT | HM-658-2C |
| Screw diameter | mm | Ø60,Ø55 |
| Max. Injection volume | cm3 | 600,550 |
| Heating bands power | kw | 5×2 |
| Temperature control | point | 4 |
| Screw rotation speed | r.p.m | 0-350 |
| Max. Injection stroke | mm | 200 |
| Motor | hp | 15×2 set |
| Clamping force | ton | 70 |
| Work stations | stations | 20 |
| Space for mould | mm | 420x320x220 |
| Machine dimension | mm(LxWxH) | 3950x3950x2200 2700x1600x2300 |
| Installation dimension | mm(LxWxH) | 7000x7000x2300 |
| Machine weight | kg | 95000 |
Remarks:
1,The machine one year warranty;
2,Installation place we will send technical personnel to the buyer for 3-7 days;
4, The buyer is responsible for visas and air tickets and shall be responsible for the food and lodging;
5,More than 7 days, the buyer will provide us engineer daily $100;
Any confusion, pls. feel free to contact us . Looking forward to cooperating with YOU!
