Help CenterAuto Brick Cutter
Related Products
Dimension L x W x H |
2,500 x 800 x 1,400 (mm) |
Cutting Interval |
~60 (1/Min) Matched with the extruder |
Cutting Length Range |
350~200 (mm) According to requirement |
Cutting Precision |
1 (mm) |
Motor Power |
0.4 (Main) + 1.5 (Servo) = 1.9 (kw) |
Weight |
≈ 1000 (kg) |
Standard Set |
Mechanical Jacks System: Belt conveying frame, cutting mechanism, motor etc. Electric Control System: Servo motor and PLC coding unit, control cabinet, cylinder etc. |
|
Features of Type TL-QDJ-LS /TB The Cutter made of leading technology droved and controlled by servo motor and PLC coded program checking and feedback the length and speed parameters of the clay column continuous extruded, then vertical conveying & cutting it to fixed length synchronously. For its unique design and technical know-how, the cutter is absolute superior to other traditional cutters in 6N+2L+3H listed below, it is truly the best choice of the kind of split-tiles manufacturing line of modern and high level. 6N---No cutting leftover margins, No cutting leftover margins recycle process, No man-made error, No surface default caused by sliding friction, No kerosene used, No pollutions to workers health and environment and might be hidden fire danger caused by kerosenes volatilization. 2L---Low workers cost (for there are less workers needed), Low materials cost (since there is no needed kerosene for lubricating). 3H---High quality (for the high precision, auto-chamfering and sliding friction default eliminated), High out put (for no leftover margins synchronously cutting process and high efficient), High performance-price ratio (for lower cost while high quality and out put automatically). | |
