EQUIPMENT FOR CUTTING
Major Technical Parameters of Vertical Synchronous Cutter Type TL-QDJ-LSTB-SF Series | |||
| |||
|
Dimension L x W x H (mm) |
Cutting Frequency (Synchronous with the extruder) (1/min) |
Capacity (Pieces/min) |
Cutting Precision (mm) |
2,750 x 840 x 1,450 |
1~ 60 |
120~180 |
±1 |
|
Motor Power (kw) |
Cutting Length Range (mm) |
Cutting Width Range (mm) |
Net Weight (kg) |
2.25 |
40~270 |
200~250 |
≈ 1500 |
Features of This Type TL-QDJ-LSTB-SF
1. Patterned technology specially made for the stood conveying and cutting process synchronously matched with high-grade and high-volume extruded wet-forming green ceramic tiles and bricks,especially for making the high-class split tiles, woody tiles, clay bricks etc.
2. Superior features of 6N+2L+3H ensure high quality and efficient production. (6N--No cutting leftovers & its recycle process, No man-made errors, No sliding friction surface default, No kerosene used & its pollution problem. 2L--Low worker’s & material’s cost. 3H--High cutting precision, out put and performance-price ratio).
3. Multi-acting cutting unit of SF type can servo driven, controlled and adjustable for double-acting or treble-acting according to the specific requirement
Engineers available service machinery overseas
Warranty : 12 month
Foshan Tech-Leader Machinery Equipment Co., Ltd. with the brand name of TELE MACHINE is located in the beautiful & famous China ceramic city -- Foshan, Guangdong province. Since its establishment, TELE MACHINE has been committed to the research & development & manufacturing of the process machines for new varieties tiles& bricks of clay or ceramic building materials. Haven nearly 20 years of industry experiences and won 70 patents in the field of intellectual property rights of technology, we are the State High-Tech Enterprises, Guangdong Civil-Run Science and Technology Enterprises, Foshan Intellectual Property Right Pilot
Enterprises and one of the first batch Guangdong Low-Carbon Pilot Enterprises in Foshan. Focus on supplying tiles & bricks process machines
We focus on offering machine lines of good solution
for roof tile / split tile / hollow bricks etc.
We want to do better with you.
Overview of TELE Machine's products and service
TELE MACHINE can make the products involving clay or ceramic tiles &bricks, especially focus on the special and new one, including roofing tiles, ceramic plate, terracotta panel, split tiles, clay bricks, hollow bricks, split rock, special-shaped ceramic, artificial stone plate, cubic ceramic, paving brick etc. And its recent development of unburned technology of energy saving & conservation and environmental protection green new material equipment, such as green hollow extrusion plank production equipment etc.
