Rough Cutting for Tiles

Name: Rough Cutting for Tiles
Brand: TELE MACHINE
SKU: 104796693
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Type:

Tile Forming Machine

Use:

Other, For roofing and building decoration

Place of Origin:

Guangdong, China

Foshan Tech-Leader Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

foshan

Delivery Detail:

Delivery time depends on order quantity.

Type Tile Forming Machine

Use Other, For roofing and building decoration

Place of Origin Guangdong, China

Brand Name TELE MACHINE

Model Number TL-QWJ-A

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Tile Type Other, Roofing tiles

Rough Cutting for Tiles

Major Technical Parameters of Auto Horizontal Cutter Type TL-QWJ-A

Dimension L x W x H	2,140 x 950 x 1,050 (mm)
Cut Interval/Min.	20 (times/min)
To Be Cut Tiles Width (Max.)	≤320 (mm)
Main Power	0.47 (kw)
Weight	≈ 200 (kg)
Standard Set	Mechanical Jacks System: Roller conveyer frame, Cutter mechanism and Governor etc. Electric Control System: Electric motor & Control cabinet etc.
Features of Type TL-QWJ-A Its way of working is different from the Type TL-QDJ-A or B cutters without turning action but straightforward and cutting, mainly used to form a complete set with the Hydraulic Roofing Tiles Press Type TL-YWJ-100 and TL Vacuum Extruder serials, worked between Extruder and Press to make required length cutting of semi-finished green tiles, which width was formed by mould when extruded, after the continuous clay column being roughly cut, then be transferred and fed manually or automatically to the press to form final tiles. It is necessary in production lines of roofing tiles featured with compact structure, flexible to use and easy to handle.
