Help Center400V 3A AC-DC Rectifier
Related Products
-
EPS Power Supply ModuleUS$ 350 - 400MOQ: 1 Unit -
Switching Power SupplyUS$ 350 - 400MOQ: 1 Unit
-
400V DC Switch Mode Power SupplyUS$ 500 - 600MOQ: 1 Unit
-
400V Fire Power/rectifier/charger/dc Power SupplyUS$ 200 - 260MOQ: 1 Unit
-
110V 3A Emergency Power Supply Module/EPS/ac-dc RectifierUS$ 50 - 700MOQ: 1 Unit
Specifications
1.Modular design2.high effiency, high reliablity
3.Multiple protections
4.wide ourput
5. mounting bracket is available
|
Mode Item |
TH400X03ZZ |
||
Output current(A) |
3 |
||
Power(KW) |
1.3 |
||
Weight(kg) |
5 |
||
Cooling method |
Natural cooling |
||
Interior radiator temperature rise |
≤30°C |
||
Output adjustment range(VDC) |
minimum |
300 |
|
Typical value |
405 |
||
maximum |
450 |
||
Over voltage protection |
480±20VDC |
||
Input voltage range(VAC) |
minimum |
323 |
|
Typical value |
380 |
||
maximum |
437 |
||
Stability precision of voltage |
±0.5% |
||
Stability precision of current |
±1% |
||
Power factor |
≥0.93 |
||
Efficiency |
≥90% |
||
Maximum noise(dB) |
50 |
||
Storage temperature(°C) |
minimum |
-40 |
|
Typical value |
25 |
||
maximum |
60 |
||
Working temperature(°C) |
minimum |
-10 |
|
Typical value |
25 |
||
maximum |
40 |
||
Parallel instability |
±5% |
||
Start up time(s) |
3~8 |
||
Ripple coefficient |
≤0.5% |
||
Over current protection |
When the output current exceeds limit value, it will stable output. The output current will not increase. |
||
Output shot circuit protection |
the module will start self-protection once short circuit and recover to work after trouble shooting. |
||
