Help CenterSingle Phase STS Keypad Prepaid Energy Meter
Related Products
-
Three Phase STS Keypad Prepaid Energy MeterUS$ 10 - 20MOQ: 10 Pieces -
China Energy Meter Manufacturer Single Phase STS Keypad Prepaid Energy MeterUS$ 18.00 - 30.00MOQ: 100 Pieces
-
Single Phase STS Keypad Smart Prepaid Energy MeterUS$ 16.50 - 18.50MOQ: 100 Units
-
Single Phase STS Keypad Prepaid Meter for Indonesia MarketUS$ 10 - 20MOQ: 10 Pieces
-
Single Phase Keypad Prepaid Energy Meter With Plug in GPRS ModuleUS$ 10 - 20MOQ: 10 Pieces
Main Features
Energy Measurement
Total and time-sharing forward active & reactive energy measurement
Total and time-sharing reverse active & reactive energy measurement
Save last one to sixteen months energy data
20 digit Standard Transfer Specification(STS)
Credit data transfered from a point of sale (POS) or vending system is made into a numeric token in a 20 digit number using the Standard Transfer Specification (STS) encryption techniques, which comply with IEC62055 protocol
Load control function
When the residual energy is 0 or the allowable overdraft that both sides agreed, this meter will send out power-off signal to have load switch cut off power. The power will be recovered automatically after inputting new purchased energy amount.
Programmable low credit warning
The meter can be programmed for setting user credit warning threshold, When the meter’s residual energy is equal to credit warning threshold, the meter will start the audio & video warning function in a way of warning light flashing
Tamper detection
With event recording function (including cover-opening event, tamper event and power failure event)
Optical port interface
Communication standards DL/T645-2007, 1200bps for communication
Support IEC62056-21 protocol
RS-485 serial interface
Communication standards DL/T645-2007, 2400bps for communication
Support IEC62056(DLMS/COSEM) protocol
LCD display
Number of digits value field Up to 8
Digit size 4x10mm
