Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Tablet Equipment > Big Pressure Tablet Press Zp-15b

Big Pressure Tablet Press Zp-15b

Name: Big Pressure Tablet Press Zp-15b
Brand: Minhua
SKU: 104707935
Availability: InStock

Big Pressure Tablet Press Zp-15b thumbnail-1

Big Pressure Tablet Press Zp-15b photo-1

US$ 1 - 2 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

Minhua

Contact Supplier Request Quote Chat Now

Minhua Pharmaceutical Machinery Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shanghai, China

Brand Name Minhua

Model Number ZP-15B

Type Rotary Tablet Press

Production Capacity 9000 pcs per hour

Max. Pressure(KN) 150KN

Max. Tablet Thickness(mm) 17mm

Max. Tablet Diameter(mm) 55mm

Voltage 380

Power(W) 4000

Weight 1500

Dimension(L*W*H) 920x890x1540

Certification ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.big pressure tablet press ZP-15B
2.150KN
3.max diameter 55mm

Specification:

This machine is suitable for pressing round tablets form various kinds of granular materials, but also different geometrical shape tablet ,specially for small-scale batch production .During operation ,the speed of turret rotation .the depth of filling material and the thickness of the tablets can be adjusted .The pre-pressure unit and over-load protection unit is included in the system ,The mechanical buffer unit will prevent punches and apparatus from overload damage ,A power suction unit is attached to take the residual power during operation ,so that the blockage by the residual power can be eliminated and collected power material can be reused.

Technical Parameter:

Punching dies	15 sets(substandard)
max working pressure	150 KN
max. Dia. of tablet	55 mm
max. thickness of tablet	17mm
Max .depth of filling	35 mm
speed of rotary table	10 r/min
produce capacity	9000 pc/h
Motor Power	4 kw
Overall Size	920×890×1540mm
Net weight	1500 kg
Voltage	380V/50HZ
