Help CenterRotary Tablet Press ZPW-29
Related Products
Specifications
1.rotary tablet press2. max diameter 25mm
ver GMP
The machine makes various kinds of particle form raw materials to round slice, is the basic equipment suitable for pressing types ,two sets of reinforced devices and two sets of press wheel .On the rotary table it can hold 33 pairs of trimming ,rotating a circle it can suppress 66 slices ,the speed of the rotary table while tablet-press ,the depth of filling with material and thickness of tablet-press are all adjustable ,Machinery amble outfit for journey of plane can avoid damage caused by overload ,In the machine there is a case of sucking powder .through mouth of sucking
It can draw machine dust produced when turning round ,prevent the dust from gluing and forming stopping up ,and reclaim raw materials .
Main technical specifications:
Dies (sets) |
29 |
Max .Pressure (KN) |
40 |
Max .Dia of Tablet (mm) |
22 |
Max .Depth of Fill (mm) |
35 |
Max .Thickness of Tablet (mm) |
18 |
Turret Speed (r /min) |
11-28 |
Production Capacity (pc/h) |
40000-8000 |
Motor (KW) |
2.2 |
Overall Size |
950x960x1600 |
Net Weight |
850 |
Packing:
Export Stand Packing
